P. 196
EXTERNAL MEASURING INSTRUMENTS Schut for Precision
Overview Krœplin external measuring instruments
External measuring instruments Oditest Digital external measuring instruments
Item No. Measuring Meas. depth Type Insert length Item No. Measuring Meas. depth Type Insert length
range/mm L/mm of insert Hb Hf range/mm L/mm of insert Hb Hf
854.909 0 - 10 35 ø 1.5 19.1 18.6 854.905 0 - 10 35 ø 1.5 19.1 18.6
854.910 0 - 10 35 ø 6 21.7 14.8 854.961 0 - 10 35 R0.4 18.8 18.5
854.911 0 - 10 35 ø 1.5 19.1 0.9 854.906 0 - 10 35 ø 6 21.7 14.8
854.912 0 - 10 35 R0.4 18.8 0.9 854.907 0 - 10 35 ø 1.5 19.1 0.9
854.962 0 - 10 35 ø 1.5 18.8 0.9
854.934 0 - 20 85 ø 1.5 24.7 24.6
854.935 0 - 20 85 R0.4 24.7 24.6 854.908 0 - 20 85 ø 1.5 24.7 24.6
854.936 0 - 20 85 ø 10 28.2 20.7 854.963 0 - 20 85 R0.4 24.7 24.6
854.937 0 - 20 80 ø 1.5 24.7 2.5 854.955 0 - 20 85 ø 10 28.2 20.7
854.938 0 - 20 80 R0.4 24.7 2.5 854.950 0 - 20 80 ø 1.5 24.7 2.5
854.956 0 - 20 80 ø 1.5 24.7 2.5
854.033 0 - 50 167 ø 3 30 30
854.034 0 - 50 167 R0.75 30 30 854.027 0 - 30 116 ø 3 30 30
854.035 0 - 50 167 ø 50 36 24 854.036 0 - 30 116 R0.75 30 30
854.038 0 - 50 169 ø 3 30 4.3 854.029 0 - 30 116 ø 50 36 24
854.039 0 - 50 169 R0.75 30 4.3 854.028 0 - 30 116 ø 3 30 4
854.037 0 - 30 116 ø 3 30 4
854.225 0 - 100 375 ø 5 33 33
854.109 0 - 100 382 ø 5 35 15 854.030 0 - 50 167 ø 3 30 30
854.226 0 - 100 375 ø 50 39 7 854.032 0 - 50 167 ø 50 36 24
854.363 0 - 100 530 ø 5 30 30 854.031 0 - 50 169 ø 3 30 4.3
854.364 0 - 100 530 ø 5 30 124
854.365 0 - 100 550 ø 50 34 14
854.366 0 - 200 728 20 98 98
➀ ➁➂
TC-B ø 1.5, R = 0.4 TC-B ø 1.5,
3 or 5 mm or 0.75 mm 3 or 5 mm
Types of inserts ➈ ➉
➃➄➅➆
R = 0.4 TC-B ø 1.5 mm R = 0.4 mm; ø 6, 10 or 50 mm ø 5 mm ø 5 mm SR 20 mm C04.243.EN.20250106
or 0.75 mm; TC-B ø 1.5
TC-B ø 1.5 mm or ø 3 mm
© 2025, Schut Geometrische Meettechniek bv 196 Measuring instruments and systems 2023/2024
