EXTERNAL MEASURING INSTRUMENTS Schut for Precision

Käfer thickness gauges

 Measuring range: 0 - 50 mm.  Different types of inserts available (a, b, c, d,
 Graduation: 0.1 mm, 0.01 mm or 0.001 mm. e).
 Standard type of insert: C, ø 10 mm.
 Interchangeable measuring inserts.

Item No. Measuring Graduation Throat Price
range/mm mm depth/mm EUR

852.346 852.346 0 - 10 0.1 50 131.00
132.00
851.714 0 - 20 0.1 50 152.00
852.370 0 - 30 0.1 50 229.00
852.747 0 - 50 0.1 50 172.00
852.100 0 - 30 0.1 100 197.00
852.277 0 - 30 0.1 200 232.00
851.819 0 - 30 0.1 300 265.00
851.969 0 - 30 0.1 400 150.00
851.713 0 - 10 0.01 50 189.00
851.785 0 - 10 0.01 100 228.00
851.702 0 - 10 0.01 200 234.00
852.747 851.816 0 - 5 0.001 50

Options: 0.50
495.157 Spare battery type CR2032 81.00
852.716 * Stand for thickness gauges

* For thickness gauges with a throat depth of 100 mm or less.

30 19 ab cd e ø1/8"
C04.329.EN.20240625ø1/8"
ø30 ø20 R15
100 Rubber, felt, ø10 ø10
soft materials
852.716 852.716 Standard contact point Hard leather, Sheets,
Soft leather, fibrous plates hard materials

cardboard, foils

Käfer pocket thickness gauges

 Measuring range: 0 - 20 mm.  Different types of inserts available.
 Graduation: 0.1 mm or 0.01 mm.  Standard type of insert: ø 6.35 mm flat insert.

Item No. Measuring Graduation Throat Price
depth/mm EUR
851.967 range/mm mm
851.712 15 64.00
851.783 0 - 10 0.1 15 73.00
852.744 0 - 20 0.1 12 131.00
0 - 8 0.01 18 127.00
0 - 10 0.01

851.783

851.967 Standard Optional Optional Optional
© 2024, Schut Geometrische Meettechniek bv contact point contact point contact point contact point
6.35 mm Ø flat 10 mm Ø flat
convex spherical

200 Measuring instruments and systems 2023/2024
