Krœplin external measuring instruments Oditest

External measuring instrument in a version which is highly accurate and reliable.

 Measuring range: 0 - 200 mm.  Dust and drip proof.
 Graduation: 0.005, 0.01, 0.05, 0.1 or 0.2 mm.  Damped movement of the measuring arm.
 Very fine tolerances on the various parts.  Adjustable tolerance markers.
 Impact and shock-resistant housing.  Protection: IP65.
 Delivery with a manufacturer measuring report.

854.934

For specifications refer to the Krœplin external
measuring instruments overview.

Item No. Type Meas. Gradu- Accu- Repeat- Price
range ation racy ability EUR
mm mm mm mm

854.909 D110 0 - 10 0.005 ± 0.015 0.005 429.40
854.910 D110T 0 - 10 0.005 ± 0.02 0.005 429.40
854.911 D1R10 0 - 10 0.005 ± 0.015 0.005 429.40
854.912 D1R10S 0 - 10 0.005 ± 0.015 0.005 429.40

854.934 D220 0 - 20 0.01 ± 0.03 0.01 429.40
854.935 D220S 0 - 20 0.01 ± 0.03 0.01 429.40
854.936 D220T 0 - 20 0.01 ± 0.04 0.01 429.40
854.937 D2R20 0 - 20 0.01 ± 0.03 0.01 429.40
854.938 D2R20S 0 - 20 0.01 ± 0.03 0.01 429.40

854.033 D450 0 - 50 0.05 ± 0.05 0.025 494.20
854.034 D450S 0 - 50 0.05 ± 0.05 0.025 494.20
854.035 D450T 0 - 50 0.05 ± 0.1 0.05 530.60
854.038 D4R50 0 - 50 0.05 ± 0.05 0.025 494.20
854.039 D4R50S 0 - 50 0.05 ± 0.05 0.025 494.20

854.225 * D8100 0 - 100 0.1 ± 0.15 0.1 932.40
854.109 * D8R100 0 - 100 0.1 ± 0.15 0.1 932.40
854.226 * D8100T 0 - 100 0.1 ± 0.15 0.1 932.40
854.363 * D12100 0 - 100 0.1 ± 0.3 0.2 1,151.60
854.364 * D12100BJ 0 - 100 0.1 ± 0.3 0.2 1,235.80
854.365 * D12100T 0 - 100 0.1 ± 0.3 0.2 1,235.80
854.366 * D16200 0 - 200 0.2 ± 0.4 0.2 1,235.80

Options: 31.90 C04.241.EN.20240625
859.233 Wooden case type 1732-45 47.10
854.098 Wooden case type 1732-51

* Delivery incl. wooden case. 859.233
