INTERNAL MEASURING INSTRUMENTS Schut for Precision

Krœplin digital internal measuring instruments

Krœplin’s new generation of quicktest measuring instruments has a compact, ergonomical design.
The digital-analog display makes read-out easier.

 Measuring range: 2.5 - 200 mm.  With tolerance display by means of red/green
 Resolution: 0.001, 0.002, 0.005, 0.01, 0.02 or LED.

0.05 mm, adjustable.  Hold and min/max functions.
 mm/inch conversion.  Protection: IP67.
 ABS/INC switchable.  Delivery with a manufacturer measuring report.
 Mitutoyo Digimatic, Mitutoyo U-WAVE,  Power supply: 2 batteries type AAA.

Bluetooth and USB data outputs optionally
available.
 Automatic switch-off.
 Storage for 100 measuring values.
 Reset/preset.

Item No. Type Measuring Accuracy Repeatability Price 854.915
range/mm mm mm EUR
854.113
854.913 L102 2.5 - 12.5 ± 0.015 0.005 441.50
854.914 L105 5 - 15 ± 0.015 0.005 441.50 For specifications refer
to the Krœplin internal
854.915 L210 10 - 30 ± 0.03 0.01 441.50 measuring instruments
854.916 L220 20 - 40 ± 0.03 0.01 441.50 overview.
854.917 L230 30 - 50 ± 0.03 0.01 441.50
854.918 L240 40 - 60 ± 0.03 0.01 441.50
854.919 L250 50 - 70 ± 0.03 0.01 441.50
854.920 L260 60 - 80 ± 0.03 0.01 441.50
854.921 L270 70 - 90 ± 0.03 0.01 441.50
854.960 L280 80 - 100 ± 0.03 0.01 441.50

854.012 L313 13 - 43 ± 0.04 0.02 441.50
854.013 L330 30 - 60 ± 0.04 0.02 441.50
854.014 L350 50 - 80 ± 0.04 0.02 441.50
854.015 L370 70 - 100 ± 0.04 0.02 441.50
854.016 L390 90 - 120 ± 0.04 0.02 441.50

854.017 L415 15 - 65 ± 0.05 0.03 610.60
0.03 610.60
854.018 L440 40 - 90 ± 0.05 0.03 610.60
0.03 610.60
854.042 L470 70 - 120 ± 0.05 0.03 655.50

854.100 L4100 100 - 150 ± 0.05 0.80
47.10
854.700 * L4150 150 - 200 ± 0.05 72.00
124.00
Options: Battery type AAA (2 needed) 98.00
497.914 Interface type 1961-09 109.20
854.952 1 Digimatic cable 9.60
965.013 1 USB cable 53.40
206.380 1 U-WAVE cable 54.20
102.790 1 Bluetooth interface adapter type 1961-13 (only K and L series)
854.092 2 Bluetooth PC dongle type 0682-60
854.073 Wooden case type 1732-65 (only K and L series)
854.113 Wooden case type 1732-71 (only K and L series)
854.084

1 For data output an interface and cable are needed. C04.301.EN.20250106
2 Bluetooth interface adapter is delivered with a Bluetooth PC dongle (854.073).
* Delivery incl. wooden case.
