Schut Geometrical Metrology INTERNAL MEASURING INSTRUMENTS
Digital internal measuring instruments
Digital internal measuring instruments for measurements of bores, internal grooves and other
hard‑to‑reach places.
Measuring range: 5 - 60 mm. Reset/preset.
Resolution: 0.005 mm. Digital-analog display Hold and min/max functions.
Adjustable tolerance limits.
changes automatically between 0.01, 0.02 and Measuring faces with different contact points.
0.05 mm (± 20 scale divisions). Delivery in an aluminum case.
mm/inch conversion. Power supply: 1 battery type CR2032.
ABS/INC switchable.
Large LCD display, 340° rotatable.
On/off switch.
Automatic switch-off.
908.810
Item No. Measuring Accuracy Length/mm Contact Price
range/mm mm L A B point/mm EUR
Range 10 mm:
908.810 5 - 15 ± 0.02 20 1 1.5 R 0.3 124.00
908.811 10 - 20 ± 0.02 25 1.5 3.0 R 0.3 135.00
L
908.812 20 - 30 ± 0.02 30 2 6.5 R 0.5 135.00 A B
908.813 30 - 40 ± 0.02 30 2.5 9.0 R 0.5 135.00
908.814 40 - 50 ± 0.02 30 2.5 9.0 R 0.5 135.00
908.816 10 - 20 ± 0.02 25 1.5 3.0 ø 1.5 155.00
908.817 20 - 30 ± 0.02 30 2 6.5 ø 1.5 155.00
908.818 30 - 40 ± 0.02 30 2.5 9.0 ø 1.5 155.00
908.819 40 - 50 ± 0.02 30 2.5 9.0 ø 1.5 155.00
Range 20 mm: ± 0.03 35 1 1.5 R 0.3 135.00
908.820 5 - 25 ± 0.03 55 2 3.5 R 0.5 149.00
908.821 10 - 30 ± 0.03 80 3 6.5 R 0.5 149.00
908.822 20 - 40 ± 0.03 80 3 8.5 R 0.5 149.00
908.823 30 - 50 ± 0.03 80 3 8.5 R 0.5 155.00
908.824 40 - 60 ± 0.03 55 2 3.5 ø 1.5 171.00
908.826 10 - 30 ± 0.03 80 3 6.5 ø 1.5 171.00
908.827 20 - 40 ± 0.03 80 3 8.5 ø 1.5 171.00
908.828 30 - 50 ± 0.03 80 3 8.5 ø 1.5 178.00
908.829 40 - 60
Option: 0.50 C04.306.EN.20240625
495.157 Spare battery type CR2032
