INTERNAL MEASURING INSTRUMENTS Schut for Precision
Internal measuring instruments
Internal measuring instruments for measurements of bores, internal grooves and other
hard‑to‑reach places.
Measuring range: 5 - 60 mm. Adjustable tolerance markers.
Graduation: 0.01 mm. Measuring faces with different contact points.
Rotatable dial. Delivery in an aluminum case.
908.830
Item No. Measuring Accuracy Length/mm Contact Price
range/mm mm L A B point/mm EUR
Range 10 mm: L
908.830 5 - 15 ± 0.02 20 1 1.5 R 0.3 127.00 A B
908.831 10 - 20 ± 0.02 25 1.5 3.0 R 0.3 137.00
908.832 20 - 30 ± 0.02 30 2 6.5 R 0.5 137.00
908.833 30 - 40 ± 0.02 30 2.5 9.0 R 0.5 137.00
908.834 40 - 50 ± 0.02 30 2.5 9.0 R 0.5 137.00
908.836 10 - 20 ± 0.02 25 1.5 3.0 ø 1.5 158.00
908.837 20 - 30 ± 0.02 30 2 6.5 ø 1.5 158.00
908.838 30 - 40 ± 0.02 30 2.5 9.0 ø 1.5 158.00
908.839 40 - 50 ± 0.02 30 2.5 9.0 ø 1.5 158.00
Range 20 mm: ± 0.03 35 1 1.5 R 0.3 137.00 C04.308.EN.20240625
908.840 5 - 25 ± 0.03 55 2 3.5 R 0.5 152.00
908.841 10 - 30 ± 0.03 80 3 6.5 R 0.5 152.00
908.842 20 - 40 ± 0.03 80 3 8.5 R 0.5 152.00
908.843 30 - 50 ± 0.03 80 3 8.5 R 0.5 158.00
908.844 40 - 60 ± 0.03 55 2 3.5 ø 1.5 175.00
908.846 10 - 30 ± 0.03 80 3 6.5 ø 1.5 175.00
908.847 20 - 40 ± 0.03 80 3 8.5 ø 1.5 175.00
908.848 30 - 50 ± 0.03 80 3 8.5 ø 1.5 182.00
908.849 40 - 60
