EXTERNAL MEASURING INSTRUMENTS Schut for Precision

Krœplin digital external measuring instruments

Krœplin’s new generation of QuickTest measuring instruments has a compact, ergonomical design.
The digital-analog display makes read-out easier.

 Measuring range: 0 - 50 mm.  With tolerance display by means of red/green
 Resolution: 0.001, 0.002, 0.005, 0.01, 0.02 or LED.

0.05 mm, adjustable.  Hold and min/max functions.
 mm/inch conversion.  Protection: IP67.
 ABS/INC switchable.  Delivery with a manufacturer measuring report.
 Mitutoyo Digimatic, Mitutoyo U-WAVE,  Power supply: 2 batteries type AAA.

Bluetooth and USB data outputs optionally
available.
 Automatic switch-off.
 Storage for 100 measuring values.
 Reset/preset.

Item No. Type Measuring Accuracy Repeatability Price 854.908
range/mm mm mm EUR
854.113
854.905 K110 0 - 10 ± 0.015 0.005 441.50
854.961 K110S 0 - 10 ± 0.015 0.005 441.50 For specifications refer to the
854.906 K110T 0 - 10 ± 0.02 0.005 441.50 Krœplin external measuring
854.907 K1R10 0 - 10 ± 0.015 0.005 441.50 instruments overview.
854.962 K1R10S 0 - 10 ± 0.015 0.005 441.50

854.908 K220 0 - 20 ± 0.03 0.01 441.50
854.963 K220S 0 - 20 ± 0.03 0.01 441.50
854.955 K220T 0 - 20 ± 0.04 0.01 441.50
854.950 K2R20 0 - 20 ± 0.03 0.01 441.50
854.956 K2R20S 0 - 20 ± 0.03 0.01 441.50

854.027 K330 0 - 30 ± 0.04 0.02 441.50
854.036 K330S 0 - 30 ± 0.04 0.02 441.50
854.029 K330T 0 - 30 ± 0.06 0.04 441.50
854.028 K3R30 0 - 30 ± 0.04 0.02 441.50
854.037 K3R30S 0 - 30 ± 0.04 0.02 441.50

854.030 K450 0 - 50 ± 0.05 0.03 610.60
854.032 K450T 0 - 50 ± 0.06 0.04 610.60
854.031 K4R50 0 - 50 ± 0.05 0.03 610.60

Options: Battery type AAA (2 needed) 0.80 C04.312.EN.20250106
497.914 Interface type 1961-09 47.10
854.952 1 Digimatic cable 72.00
965.013 1 USB cable 124.00
206.380 1 U-WAVE cable 98.00
102.790 1 Bluetooth interface adapter type 1961-13 109.20
854.092 2 (only K and L series)
Bluetooth PC dongle type 0682-60 9.60
854.073 Wooden case type 1732-65 (only K and L series) 53.40
854.113 Wooden case type 1732-71 (only K and L series) 54.20
854.084

1 For data output an interface and cable are needed.
2 Bluetooth interface adapter is delivered with a Bluetooth PC dongle (854.073).
