Schut Geometrical Metrology EXTERNAL MEASURING INSTRUMENTS

Käfer foil thickness gauges Available types of inserts:
– ø 6.35 mm flat.
 Measuring range: 0 - 3 mm. – ø 10 mm flat.
 Resolution: 0.001 mm. – Upper insert convex r 15 or r 40,
 Standard type of insert: ø 6.35 mm flat.
 Different types of inserts available. lower insert ø 6.35 mm flat.
– Lower insert convex r 15.
– Spherical.

Item No. Measuring Type of insert 1 pointer Throat Price
range/mm revolution depth/mm EUR
851.760
851.760 852.368 1 6.35 mm 0.2 mm 30 277.00
852.263 851.711 1 6.35 mm 0.1 mm 30 302.00
852.263 0.1 6.35 mm 0.1 mm 30 329.00
3 6.35 mm 30 709.00
Option: –
495.157 0.50
Spare battery type CR2032

Käfer thickness gauges with roller measuring inserts

 Measuring range: 0 - 10 mm.  Measuring face roller measuring inserts:
 Resolution: 0.01 mm. 8.7 mm / ø 8.4 mm.

 Throat depth: 50 mm.

Item No. Description Measuring Graduation Price
range/mm mm EUR
852.377 Thickness gauge 283.00
852.058 Digital thickness gauge 5 0.01 699.00
Option: 10 0.01
495.157 0.50
852.377 Spare battery type CR2032

Käfer digital thickness gauges

 Measuring range: 0 - 25 mm.  Standard type of insert: C, ø 10 mm.
 Resolution: 0.01 mm or 0.001 mm.  Delivery in a plastic carrying case.
 Interchangeable measuring inserts.  Power supply: 1 battery type CR2032.
 Different types of inserts available
Item No. Measuring Resolution Throat Price
(a, b, c, d, e). range/mm mm depth/mm EUR

852.741 852.768 0 - 12.5 0.01 50 540.00
852.768 852.715 0 - 25 0.01 50 625.00
852.754 0 - 25 0.01 100 668.00
852.396 0 - 12.5 0.001 50 601.00
852.741 0 - 25 0.001 200 803.00

Options: Spare battery type CR2032 0.50 C04.330.EN.20240625
495.157 RS232C cable 9p (2 m) 150.00
852.117 USB cable (2 m) 150.00
852.118 Stand for thickness gauges 81.00
852.716 *

* For thickness gauges with a throat depth of 100 mm or less.

© 2024, Schut Geometrische Meettechniek bv 201 Measuring instruments and systems 2023/2024
