Schut Geometrical Metrology                                                                              MICROMETERS

TESA Micromaster digital capa µ micrometers IP54

  This line of digital micrometers with the patented capa µ measuring system has a very light-weight
and ergonomic design and is equipped with a large easy-to-read LCD display with 7 mm large digits.
Especially the high protection degree – IP54 against dust and splash water – makes this series of micro­
meters very suitable for use in workshop conditions. The friction thimble ensures a constant measuring
force of approximately 10 N for optimal repeatability. The models with Opto-RS232C data output are
suitable for data transfer by means of a cable, or wireless with the TESA Link Connector-Bluetooth
and Opto-RS232/TLC adapter in combination with the free to download TESA Data-Viewer software.

	 Measuring range: 0 - 100 mm.                                                	 Friction thimble.
	 Resolution: 0.001 mm.                                                       	 Tungsten carbide measuring faces: ø 6.5 mm.
	 mm/inch conversion.                                                         	 Matt chrome-plated frame with insulating
	 ABS/INC switchable.
	 With or without bidirectional                                                 grip.
                                                                               	 Protection: IP54.  
  Opto-RS232C data output.
	 Automatic switch-off.                                                         (When using data output: IP40.)
	 Reset/preset and hold function.                                             	 Delivery in a plastic case or a wooden case
	 Locking screw.
                                                                                 with a manufacturer measuring report.
                                                                               	 Power supply: 1 battery type CR2032.

                                                            782.107

                                                                     Item No.     Measuring         Accuracy    Price
                                                                                  range/mm             mm       EUR

                                                                     Without Opto-RS232C data output:           395.00
                                                                     782.100 1 	  0	-	 30 	 ± 0.004             407.00
                                                                     782.101 	    0	-	 30 	 ± 0.004             514.00
                                                                     782.102 	 25	-	 50 	 ± 0.004               574.00
                                                                     782.103 	 50	-	 75 	 ± 0.005               639.00
                                                   782.105           782.104 	 75	-	100 	 ± 0.005
                                            782.111
                           782.100                                   With Opto-RS232C data output:              445.00
                                                                     782.105 	    0	-	 30 	 ± 0.004             555.00
© 2025, Schut Geometrische Meettechniek bv                           782.106 	 25	-	 50 	 ± 0.004               647.00
                                                                     782.107 	 50	-	 75 	 ± 0.005               717.00
                                                                     782.108 	 75	-	100 	 ± 0.005               885.00
                                                                     With small measuring faces ø 2 mm:
                                                                     782.111 	    0	-	 30 	 ± 0.004

                                                                     Options:                                      0.50        C03.303.EN.20250702
                                                                     495.157 Battery type CR2032                190.00
                                                                     783.556 TESA Link Connector                 54.00
                                                                                                                157.00
                                                                                Adapter Opto-RS232/TLC          301.00
                                                                     783.555 TESA Link Connector Bluetooth
                                                                     781.887 Opto-RS232C cable 9p (2 m)
                                                                     783.027 Cable USB-Opto RS232 duplex (2 m)

                                                            1	Micromaster “Easy”: simple model with protection IP40 and
                                                             without preset function.
