Schut Geometrical Metrology MICROMETERS

Mitutoyo Digimatic micrometers IP65

These digital Coolant Proof micrometers have an IP65 classification and are therefore not only
resistent to dust but can also withstand water jets and splashing coolant. The large and clear LCD
with 7.5 mm high digits enables easy read-out.

 Measuring range: 0 - 150 mm. 293.230
 Resolution: 0.001 mm.
 ABS/INC switchable. Item No. Measuring Accuracy Digimatic Price
 Automatic switch-off. range/mm mm output EUR
 Reset.
 ABS reset by means of origin. 293.240 0 - 25 ± 0.001 no 244.00
 Hold function. 293.241 25 - 50 ± 0.001 no 342.00
 Tungsten carbide measuring faces: 293.242 50 - 75 ± 0.002 no 412.00
293.243 75 - 100 ± 0.002 no 469.00
ø 6.35 mm. 293.230 0 - 25 ± 0.001 yes 315.00
 Varnished frame with insulating grip. 293.231 25 - 50 ± 0.001 yes 373.00
 Protection: IP65. 293.232 50 - 75 ± 0.002 yes 490.00
 Conforms to factory standard. 293.233 75 - 100 ± 0.002 yes 530.00
 Delivery in a plastic case with a 293.250 100 - 125 ± 0.002 yes 719.00
293.251 125 - 150 ± 0.002 yes 740.00
manufacturer measuring report 293.252 150 - 175 ± 0.003 yes 759.00
(0 - 50 mm). 293.253 175 - 200 ± 0.003 yes 765.00
 Power supply: 1 battery type V357. 293.234 1 0 - 25 ± 0.001 yes 379.00
 Battery life: approx. 2.4 years. 293.244 1 0 - 25 ± 0.001 no 261.00
 The standard model with data output
is available up to 300 mm, and is also
available in sets.
 Models with ratchet thimble or with
n1o00n- mromtatminegasspuirnindgleraanregea.vailable up to
Available up to 300 mm measuring range.

Options:
836.535 Battery type V357 0.90
105.662 2 Digimatic data cable, 1 m 105.00
293.240

105.663 2 Digimatic data cable, 2 m 107.00
106.380 2 USB Input Tool Direct cable, 2 m 141.00
102.310 2,3 U-WAVE fit connector 110.00
264.622 3 U-WAVE fit transmitter IP67 187.00
264.626 3 U-WAVE Bluetooth transmitter IP 67 187.00

293.234 1 With ratchet thimble.
2 With data switch.
3 Connector + transmitter are needed.

Sets

Item No. Measuring Pieces Price
range/mm EUR

293.966 0 - 50 2 733.00 C03.328.EN.20250321
293.962 0 - 75 3 1,252.00
293.963 0 - 100 4 1,810.00

© 2025, Schut Geometrische Meettechniek bv 99 Measuring instruments and systems 2025/2026
