Schut Geometrical Metrology MICROMETERS

Mitutoyo Digimatic and QuantuMike micrometers IP65

These digital Coolant Proof micrometers have an IP65 classification and are therefore not only
resistent to dust but can also withstand water jets and splashing coolant. The large and clear LCD with
7.5 mm high digits enables easy read-out. The revolutionary QuantuMike has a spindle pitch of 2 mm.
The spindle feed is therefore 4x faster compared to a standard micrometer. The Quantumike is easy to
set up using a PC. Even a calculation function is possible and setting a calibration date.

 Measuring range: 0 - 150 mm,
QuantuMike 0 - 100 mm.
 Resolution: 0.001 mm.
 ABS/INC switchable.
 Automatic switch-off.
 Reset. QuantuMike with
 ABS reset by means of origin. data output.

 Hold function.
 Protection against incorrect measuring
speed (only QuantuMike).
 1 revolution of the thimble = 2 mm
(only QuantuMike).
 Tungsten carbide measuring faces:
ø 6.35 mm. Item No. Measuring Accuracy Digimatic Price
 Varnished frame with insulating grip. range/mm mm output EUR

 Protection: IP65. 293.240 0 - 25 ± 0.001 no 244.00
± 0.001 no 342.00
 Conforms to factory standard. 293.241 25 - 50 ± 0.002 no 412.00
 Delivery in a plastic case with a 293.242 50 - 75 ± 0.002 no 469.00
293.243 75 - 100 ± 0.001 Digimatic 315.00
manufacturer measuring report 293.230 0 - 25 ± 0.001 Digimatic 373.00
(0 - 50 mm). 293.231 25 - 50 ± 0.002 Digimatic 490.00
 Power supply: 1 battery type V357. ± 0.002 Digimatic 530.00
293.232 50 - 75 ± 0.002 Digimatic 719.00
± 0.002 Digimatic 740.00
 Battery life: approx. 2.4 years. 293.233 75 - 100
 The standard model with data output 293.250 100 - 125 ± 0.001 no 269.00
293.251 125 - 150 ± 0.001 no 371.00
(293.230 - 293.233) is available up to ± 0.002 no 443.00
300 mm, and is also available in sets. QuantuMike: 0 - 25 ± 0.002 no 504.00
 Models with ratchet thimble are 293.145 25 - 50 ± 0.001 Digimatic S1 380.00
available up to 100 mm measuring 293.146 50 - 75 ± 0.001 Digimatic S1 468.00
range. 293.147 ± 0.002 Digimatic S1 556.00
± 0.002 Digimatic S1 628.00
293.148 75 - 100

293.140 0 - 25

293.141 25 - 50

293.142 50 - 75

293.143 75 - 100

QuantuMike without data output. Options: Battery type V357 0.90
836.535 Digimatic data cable, 1 m 105.00
105.662 1 Digimatic data cable, 2 m 107.00
105.663 1 Digimatic USB Input Tool Direct cable, 2 m 141.00
106.380 1 Digimatic U-WAVE fit connector 110.00
102.310 1,2 Digimatic S1 data cable, 1 m
106.111 1 Digimatic S1 data cable, 2 m 187.00
106.121 1 Digimatic S1 USB Input Tool Direct cable, 2 m 187.00
206.001 1 Digimatic S1 U-WAVE fit connector
102.960 1,2 U-WAVE fit transmitter IP67
264.622 2 U-WAVE Bluetooth transmitter IP 67
264.626 2

1 With data switch. C03.302.EN.20250106
2 Connector + transmitter are needed.
