Page 102 - Schut Catalog
P. 102
MICROMETERS Schut for Precision
Mitutoyo Absolute Digimatic Submicrometer MDH
Micrometer with a higher resolution (switchable) and accuracy.
Measuring range: 0 - 25 mm. Locking screw.
Resolution: 0.0001 or 0,0005 mm. Tungsten carbide measuring faces: ø 3.2 mm.
Digimatic data output. Varnished frame with insulating grip.
On/off switch. Absolute rotary sensor.
Automatic switch-off. Weight: 400 g.
Reset/preset. Conforms to factory standard.
Hold function. Delivery in a plastic case with a manufacturer
Measuring force: 7 - 9 N.
Spindle: ø 6.35 mm. measuring report.
Power supply: 1 battery type CR2032.
Item No. Measuring Accuracy Price
range/mm mm EUR
293.100 0 - 25 ± 0.0005 2,006.00
Options: 0.50
495.157 Spare battery type CR2032 105.00
105.662 1 Digimatic data cable, 1 m 107.00
105.663 1 Digimatic data cable, 2 m 141.00
106.380 1 USB Input Tool Direct cable, 2 m 110.00
102.791 1 U-WAVE data cable
1 With data switch.
Mitutoyo Quick Mini digital quick thickness gauge
The measuring instrument to always carry with you. Pull back the lever, insert the sample, release
the lever and read the value!
Measuring range: 0 - 12 mm. Reset.
Resolution: 0.01 mm. Measuring force: 2 N.
Accuracy: ± 0.02 mm. Anvil measuring face: ø 6.5 mm.
Repeatability: 0.01 mm. Pin measuring face: ø 5 mm.
ABS/INC switchable. Delivery in a plastic case.
Power supply: 1 battery type V357.
Item No. Measuring range/mm Price EUR
700.119 0 - 12 198.00
Option: 0.90 C03.316.EN.20240625
836.535 Spare battery type V357
© 2024, Schut Geometrische Meettechniek bv 102 Measuring instruments and systems 2023/2024
