MICROMETERS Schut for Precision

TESA Micromaster digital capa µ micrometers IP54

This line of digital micrometers with the patented capa µ measuring system has a very light-weight
and ergonomic design and is equipped with a large easy-to-read LCD display with 7 mm large digits.
Especially the high protection degree – IP54 against dust and splash water – makes this series of micro­
meters very suitable for use in workshop conditions. The friction thimble ensures a constant measuring
force of approximately 10 N for optimal repeatability. The models with Opto-RS232C data output are
suitable for data transfer by means of a cable, or wireless with the TESA Link Connector-Bluetooth
and Opto-RS232/TLC adapter.

 Measuring range: 0 - 300 mm.  Friction thimble.
 Resolution: 0.001 mm.  Tungsten carbide measuring faces: ø 6.5 mm
 mm/inch conversion.
 ABS/INC switchable. (from measuring range 100 - 125 mm: ø 8 mm).
 With or without bidirectional  Matt chrome-plated frame with insulating

Opto-RS232C data output. grip.
 Automatic switch-off.  Protection: IP54.
 Reset/preset and hold function.
 Locking screw. (When using data output: IP40.)
 Delivery in a plastic case or a wooden case

with a manufacturer measuring report.
 Power supply: 1 battery type CR2032.

782.107 Item No. Measuring Accuracy Price
range/mm mm EUR

Without Opto-RS232C data output: 395.00
782.100 1 0 - 30 ± 0.004 407.00
782.101 0 - 30 ± 0.004 504.00
782.102 25 - 50 ± 0.004 563.00
782.103 50 - 75 ± 0.005 628.00
782.104 75 - 100 ± 0.005

782.105 With Opto-RS232C data output: 437.00
782.105 0 - 30 ± 0.004 545.00
782.100 782.106 25 - 50 ± 0.004 636.00
782.107 50 - 75 ± 0.005 704.00
782.108 75 - 100 ± 0.005 918.00
782.115 100 - 125 ± 0.006 935.00
782.116 125 - 150 ± 0.006 966.00
782.117 150 - 175 ± 0.007 1,073.00
782.118 175 - 200 ± 0.007 1,150.00
782.119 200 - 225 ± 0.008 1,158.00
782.122 225 - 250 ± 0.008 1,166.00
782.123 250 - 275 ± 0.009 1,177.00
782.124 275 - 300 ± 0.009

Options: 0.50
495.157 Spare battery type CR2032
783.556 TESA Link Connector 182.00
Adapter Opto-RS232/TLC
783.555 TESA Link Connector Bluetooth 52.00
781.887 Opto-RS232C cable 9p (2 m) 157.00
C03.303.EN.20240625
1 Micromaster “Easy”: simple model with protection IP40
and without preset function.
