P. 474
HEIGHT GAUGES Schut for Precision
TESA-Hite Magna / TESA-Hite 400/700
The TESA-Hite height gauges have a simple and robust design and are therefore very suitable
for use in a workshop to measure heights, grooves, diameters, pitch circle, center distances and
parallelism using a constant measuring force.
Thanks to the robust magnetic measuring system, the TESA-Hite Magna is very suitable for use in
harsh environments. The TESA-Hite is suitable for more accurate measurements due to the optical
measuring system.
The clear and bright IP65 classified color screen only shows relevant data and has context-sensitive
menus and built-in help for easy operation.
The height gauges are equipped with fine adjustment, locking screw and a stable cast iron base,
with the TESA-Hite having a built-in air cushion for smooth movement.
Data can be sent to a PC for processing and storage using the (wireless) TESA Link Connector and
the free TESA DATA VIEWER PC software.
Measuring range: 415 and 715 mm resp. For optional probes and accessories see
Max. range with standard probe holder: “Probes and accessories TESA Micro‑Hite /
TESA‑Hite”.
570 and 870 mm resp.
Max. range with long probe holder (782.358): TESA-Hite Magna 400/700
Equipped with a robust magnetic measuring
795 and 1095 mm resp.
Easy-to-read LCD-color display. system.
Process and store data on the PC using the Resolution: 0.001 / 0.005 / 0.01 mm.
Accuracy: ± 8 µm.
TESA Link Connector data output. Repeatability:
Measuring force: 1.5 ± 0.5 N.
SCS certificate included. ≤ 3 µm (flat surfaces), ≤ 5 µm (radius).
Weight: 783.565: 15 kg, 783.566: 18 kg.
Protection: IP55, control panel: IP65.
Detailed TESA-Hite 400/700
information Measuring with higher accuracy, also for
available measuring perpendicularity. Air cushion
pump for easy movement on a surface plate.
783.565 Squareness can be measured using optional
probe, holder and display.
783.568 Resolution: 0.0001 / 0.001 / 0.01 mm.
Accuracy: ± (2.5 + 0.004L) µm (L in mm).
Standard accessories Repeatability:
The TESA-Hite Magna / TESA-Hite
≤ 2 µm (flat surfaces), ≤ 3 µm (radius).
400/700 is standard supplied with: Squareness (frontal): 9 and 13 µm resp.
– standard probe holder (783.511), Weight: 783.567: 24 kg, 783.568: 30 kg.
– TC ball probe ø 5 mm (782.215), Protection control panel: IP65.
– reference standard 6.35 mm,
– electric pump (only TESA-Hite), Item No. Type/description Price EUR
– Li-ion battery,
– AC adapter (783.570) incl. power cable 783.565 1 TESA-Hite Magna 400
783.566 1 TESA-Hite Magna 700
(782.202), 783.567 1 TESA-Hite 400
– SCS calibration certificate. 783.568 1 TESA-Hite 700
Options: TESA Link Connector USB C16.272.EN.20240626
783.301 2 TESA Link Connector Digimatic
783.302 2 TESA Link Connector Bluetooth
783.555 2
1 Delivery ex Groningen, Netherlands.
2 The TESA Link Connector will replace the battery cover.
© 2024, Schut Geometrische Meettechniek bv 474 Measuring instruments and systems 2023/2024
