P. 469
Schut Geometrical Metrology HEIGHT AND SCRIBING GAUGES
Height and scribing gauges with dial and counter
Measuring range: 0 - 1000 mm.
Graduation dial indicator: 0.01 mm.
Resolution counter: 1 mm.
1 pointer revolution = 1 mm.
Rotatable dial.
Double counter, one indicator in plus
direction and one in minus direction.
Zero setting possible at any height.
Intake scriber: 9 x 9 mm.
Delivery incl. scriber.
Item No. Measuring Accuracy Price
range/mm mm EUR
906.250 0 - 300 ± 0.04 212.00 906.250
906.251 0 - 450 ± 0.05 329.00
906.252 0 - 600 ± 0.05 429.00
906.253 0 - 800 ± 0.06 1,934.00
906.254 1 0 - 1000 ± 0.07 2,100.00
Option: 19.80
906.174 Scriber 9 x 9 mm
1 Delivery ex Groningen, Netherlands. 906.253
Height and scribing gauges with dial
These height gauges are equipped with a rack, as used for
dial calipers.
Measuring range: 0 - 300 mm.
Graduation: 0.02 mm.
1 pointer revolution = 2 mm.
Rotatable dial.
Fine adjustment.
Delivery in a wooden case with a scriber.
Item No. Measuring Accuracy Price
range/mm mm EUR
72.00
906.260 0 - 150 ± 0.03 77.00
906.261 0 - 200 ± 0.03 90.00
906.262 0 - 300 ± 0.04
15.00
Options: 15.00 906.260 C16.204.EN.20240626
906.029 Scriber for 906.260/261 Measuring instruments and systems 2023/2024
906.049 Scriber for 906.262
© 2024, Schut Geometrische Meettechniek bv 469
