P. 467
Schut Geometrical Metrology HEIGHT AND SCRIBING GAUGES
Mitutoyo digital height and scribing gauges
Ergonomically designed height gauge with data output and a useful hand wheel for both fast and
fine adjustment.
Measuring range: 0 - 1000 mm.
Resolution: 0.005 / 0.01 mm.
Accuracy: refer to table.
ABS/INC switchable.
Digimatic data output.
On/off switch.
Reset/preset.
Hold function.
Max. measuring speed: 500 mm/s.
Reversible measuring direction.
Fast and fine adjustment.
Interchangeable scriber, intake 9 x 9 mm.
Delivery incl. cover and scriber.
Conforms to factory standard.
Power supply: 1 battery type V357.
Data cables Digimatic, 192.663
USB Input Tool Direct, U-WAVE 192.613
available on request.
With a connection for a probe
Item No. Measuring Resolution Accuracy Price 192.007
range/mm mm mm EUR
192.663 0 - 300 0.005 / 0.01 ± 0.02 1,385.00
192.664 0 - 600 0.005 / 0.01 ± 0.04 1,803.00
192.665 1 0 - 1000 0.005 / 0.01 ± 0.06 3,068.00
Options: 0.90
836.535 Spare battery type V357 167.00
905.201 Scriber 46.00
105.033 Scriber holder 606.00
192.007 Electronic probe
1 Delivery ex Groningen, Netherlands.
Without connection for a probe
Item No. Measuring Resolution Accuracy Price
range/mm mm mm EUR
192.613 0 - 300 0.005 / 0.01 ± 0.02 1,059.00
192.614 0 - 600 0.005 / 0.01 ± 0.05 1,454.00
192.615 1 0 - 1000 0.005 / 0.01 ± 0.07 2,746.00
Options: 0.90 C16.271.EN.20240626
836.535 Spare battery type V357 69.00
107.001 Scriber 9 x 9 mm 46.00
105.033 Scriber holder
1 Delivery ex Groningen, Netherlands.
© 2024, Schut Geometrische Meettechniek bv 467 Measuring instruments and systems 2023/2024
