Schut Geometrical Metrology HEIGHT AND SCRIBING GAUGES

Absolute digital height and scribing gauges

Digital height and scribing gauges with an absolute measuring system. Combined with a Digimatic
dial indicator quick and accurate measurements can be performed with a constant measuring force.

 Measuring range: 0 - 600 mm.  Delivery incl. scriber, dial indicator holder
 Resolution: 0.01 mm. and Digimatic data cable for dial indicator.
 Handwheel drive for easy head displacement.
 Interchangeable scriber, intake 9 x 9 mm.  Delivery in a plastic carrying case.
 ABS/INC switchable.  Power supply: 1 battery type CR2032.
 Digimatic data output.  For suitable Digimatic dial indicators refer to
 On/off switch.
 Reset. the dial indicators elsewhere in this catalog.
 Hold function.
 Locking screw. USB interface:
– For data transfer to PC

(e.g. Excel, Word).
– Operating system:

Windows and other.
– PC connection: USB.
– No software or driver to install.
– Foot switch (optional).

910.096 910.096
Delivery without dial indicator.
Item No. Measuring Accuracy Price
909.686 range/mm mm EUR
909.687
910.039/038 910.096 0 - 300 0.03 302.00
910.097 0 - 600 0.05 435.00

With Bluetooth: 0 - 300 0.03 323.00
910.098

Options: 0.50 C16.315.EN.20240626
495.157 Spare battery type CR2032 109.00
909.686 * USB interface 18.50
909.687 Footswitch for USB interface 50.00
910.038 Wireless USB receiver 50.00
910.039 Wireless transmitter 34.60
906.256 Scriber

* Standard configured for PC with English (US) keyboard.
Also available on request for alternative keyboards.
