SCRIBING TOOLS                                                    Schut for Precision

  Universal setting instrument

  This versatile instrument is specially designed for manufacturers of very accurate products, such
as gauges and toolmakers. The guide is installed under an angle of 20° and the components can be
moved very accu­rate­ly. The movable component has several threaded bores M4, by which the setting
instrument also can be used as a scriber or height gauge.
	 Max. height range incl. extensions: 270 mm.
	 Dimensions: 133 x 64 x 18.5 mm.
	 Delivery with extensions 25 mm and 75 mm

  (equipped with thread M4/thread hole M4).
	 Base with vial.

Item No. Description                        Price EUR

906.455 Universal setting instrument 109.00              906.455

  Surface gauge

  Stable foot with V‑slot at the ground surface,
grips at the side and is also equipped with two
bores (ø 5.5 mm).
	 Foot ground all around (except for the V‑slot).
	 Fine adjustment.
	 Dimensions:

  scriber: ø 4 x 200 mm,
  arm: ø 10 x 450 mm,
  foot: 85 x 65 x 25 mm.

Item No. Description                        Price EUR                                                 C16.201.EN.20250321
906.220 Surface gauge                             35.00
