Schut Geometrical Metrology SCRIBING TOOLS

Marking calipers

T‑shaped stainless steel marking caliper with a large marking face/cross scale. The marking face is
sunk into the U‑shaped base face.

 Measuring range: 0 - 300 mm.  Matt chrome-plated beam.
 Locking screw.  Marking face/cross scale with mm graduation
 Vernier: 0.05 mm.
 With or without fine adjustment. (50 - 0 - 50 mm).

Item No. Measuring Base Price
range/mm length/mm EUR

907.196 Without fine adjustment: 140 78.00
907.575 0 - 160 140 98.00
907.576 0 - 250 160 113.00
907.577 0 - 300

With fine adjustment: 140 83.00
907.196 0 - 160 140 104.00
907.197 0 - 250 160 133.00
907.198 0 - 300

Marking gauges

 Measuring range: 0 - 300 mm.
 Vernier: 0.1 mm.
 Matt chrome-plated beam.

907.180 Item No. Measuring range/mm Price EUR

907.180 0 - 200 17.20
907.181 0 - 250 20.70
907.182 0 - 300 30.80

Digital marking gauge and protractor

 Measuring range: 0 - 300 mm. Item No. Measuring range/mm Price EUR
 Resolution: protractor: 0.05°,
906.669 0 - 300 64.00
scale: 0.01 mm.
 mm/inch conversion.
 On/off switch.
 Automatic switch-off.
 Reset.
 Hold function.
 Locking screw.
 Protection: IP40.
 Power supply: 1 battery type CR2032.

Option: C15.271.EN.20240626
495.157 Spare battery type CR2032 0.50
