HEIGHT GAUGES Schut for Precision

TESA Micro-Hite/Micro-Hite+M 350/600/900 (continued)

Control unit
The Micro-Hite/Micro-Hite+M height gauges are equipped with a 2D control unit. This completely

renewed control unit can be fully controlled using the touch screen, the physical buttons or a combi-
nation of both. Standard functions can be accessed with 1 button, making the height gauge accessible
to everyone. During measurements the display shows graphical instructions to guide you through the
measuring process. Measurements can be saved as a program. Data can be entered on the display for
traceability purposes, for instance product or operator information. After completion of the measure-
ments graphs and tables can be shown including go/nogo classification based on entered tolerance
values. The adjustable mounting allows for optimal positioning of the control unit.

The control unit features the following interfaces: 3 x USB output, 1 x RS232 output, 1 x TLC
output and can be connected to a PC using the de TLC-USB cable or the TLC-BLE transmitter
(wireless). In combination with the free TESA DATA VIEWER PC software measurements can be
exported directly to Excel. Using the STAT-EXPRES SPC software measurements can be saved and
analysed. Measuring reports (PDF), programs and measuring results can be saved directly to a USB
stick. An optional printer allows for printing of the measuring results.

Detailed Accessories for (wireless) data transfer
information available on request.

available Item No. Type/description Price EUR
783.501 1 Micro-Hite 350
783.502 1 Micro-Hite 600
783.503 1 Micro-Hite 900
783.504 1 Micro-Hite+M 350 (motorized)
783.505 1 Micro-Hite+M 600 (motorized)
783.506 1 Micro-Hite+M 900 (motorized)
Options:
783.555 TESA Link Connector Bluetooth
783.509 USB printer for Micro-Hite
783.524 Paper for USB printer (4 rolls)
1 Delivery ex Groningen, Netherlands.

Basic instrument Micro-Hite/Micro-Hite+M Basic instruments
350 600 900 The Micro-Hite/Micro-Hite+M height
Measuring range mm
365 615 920 gauges are standard supplied with:
Max. range with mm – Micro-Hite(+M) panel with adjustable holder,
– standard probe holder 6 mm (783.511),
standard holder and probe 520 770 1075 – standard probe with carbide ball tip ø 5 mm

Max. range with mm (782.215),
long probe holder 745 995 1300 – reference standard 12.7 mm,
– electric air cushion,
Max. deviation of perpen- µm – Li-ion battery, C16.303.EN.20250106
dicularity mech. (frontal) < 7 < 9 < 11 – AC adapter (783.570) incl. power cable

Max. deviation of perpen- µm (782.202),
with IG13 probe < 5 < 7 < 9 – SCS calibration certificate.
