HEIGHT GAUGES Schut for Precision
Mitutoyo height gauges QM‑Height 350/600
The Mitutoyo QM‑Height height gauge, equipped with the highly accurate Absolute linear encoder,
delivers high performance in combination with affordability. The high accuracy, repeatability and
perpendicularity make the QM‑Height very suitable to satisfy your most critical measurement needs.
Yet the lightweight, compact design and the simplicity of the controls make this a user-friendly and
flexible height gauge, suitable for use in both cleanroom and workshop. All measuring functions can
be started by pressing just one button.
The QM‑Height is equipped with many advanced measuring functions for measuring height, inside
and outside diameters, min/max values and center distances. It is also equipped with a scanfunction,
data-output, measuring memory and a Go/NoGo tolerance judgement, making human interpretation
errors almost impossible. The QM‑Height is available in two measuring ranges and Mitutoyo offers a
wide range of accessories. See for all accessories “Mitutoyo LH‑600 / QM‑Height accessories”.
Measuring range: 0 - 600 mm. Delivery with an inspection report.
Resolution: 0.001/0.005 mm. Power supply: 4 batteries type AA or optional
Accuracy: ± (2.4 + 2.1L/600) µm (L in mm).
Repeatability: 0.0018 mm. AC adapter.
USB and Digimatic data output.
Direct Go/NoGo tolerance judgement by LEDs Detailed
information
after every measurement (also on display).
An air-bearing of the base (with built-in available
compressor) allows almost feather-light
movement on a surface plate.
Measuring force: 1.5 ± 0.5 N.
Operating temperature: 0 to 40°C.
Adjustable tolerance limits.
Weight: 518.240: 25 kg, 518.242: 29 kg,
518.244: 26 kg, 518.246: 30 kg.
Data cables Digimatic,
USB Input Tool Direct, U-WAVE
available on request.
Item No. Measuring Squareness Price
range/mm µm EUR
Without air bearing: 7 518.246
518.240 1 0 - 350 12
518.242 1 0 - 600 Standard accessories:
– auxiliary grip,
With air bearing: 7 – block for probe diameter calibration,
518.244 1 0 - 350 12 – probe holder including excentric ball
518.246 1 0 - 600
probe ø 5 mm,
Options: – 4 batteries. C16.309.EN.20240626
495.111 Spare battery type AA
(4 needed)
106.369 AC adapter
1 Delivery ex Groningen, Netherlands.
