P. 482
HARDNESS TESTERS Schut for Precision
Hildebrand portable Shore hardness testers
Portable hardness testers to measure Shore hardness A or D, according
DIN ISO 48‑4 and ISO 868.
Measuring range: 0 - 100 Shore. Weight: 184 g.
Graduation: 1 Shore. Delivery in a plastic
Accuracy: ± 0.5 Shore.
Measuring length: 2.5 mm. case.
Material thickness: ≥ 6 mm. 2 year factory guarantee.
With or without extra pointer for maximum
measuring value indication.
Dial diameter: 57 mm.
Total length: 121 mm.
Type Shore A Shore D 856.005
Max. spring force 8.065 N 44.50 N
Impact module Item No. Type Price EUR
Applications 35° 30° 856.005 Shore A 534.00
Soft rubber, Hard rubber, 856.006 Shore D 534.00
elastomers, thermoplastics,
nature rubber, etc. With maximum value indication:
etc. 856.007 Shore A 584.00
856.008 Shore D 584.00
Measuring stand for Hildebrand Shore hardness testers
To increase the accuracy and repeatability of the measurements, the use of this stand is recommended.
It prevents possible errors that can occur by differences in the pressing force or when the hardness
tester is not held up right.
Max. measuring height: 180 mm. 856.012
Measuring table: ø 98 mm.
Standard equipped with a weight (1000 g)
for Shore A.
Load weight: Shore A: 274 g,
Shore D: 4000 g.
Stable aluminum construction, table of
stainless steel.
Weight: 16.4 kg.
Item No. Description Price EUR 856.010
856.010 Measuring stand 1,266.00
Options: 168.00
856.012 Weight for Shore D
856.028 Set of setting standards 297.00 856.028 C18.301.EN.20240626
(20, 40, 60 and 80 Shore)
© 2024, Schut Geometrische Meettechniek bv 482 Measuring instruments and systems 2023/2024
