Schut Geometrical Metrology THICKNESS GAUGES
Digital thickness gauges
This thickness gauge measures in a non-destructive way the thickness from several materials
according to the ultrasonic measuring principle. The Echo-Echo model is capable of measuring the
material thickness even through coatings.
A thickness gauge with glass fiber / composite probe is available for measuring glass fiber parts.
For example thicknesses of parts of cars, boats, airplanes and medical devices can be measured
ultrasonically.
Measuring range: 0.65 - 300 mm. 909.566
Resolution: 0.1 mm or 0.01 mm.
Accuracy (H = measured value):
0.65 - 9.99 mm: ± 0.04 mm,
10.00 - 99.99 mm: ± (0.1%H + 0.04 mm),
100.0 - 400.0 mm: ± 0.3%H.
Measuring frequency: 5 MHz (standard probe).
9 preset materials (aluminum, titanium, steel,
stainless steel, glass, copper, cast iron, brass
and polystyrene) and one configurable speed
of sound.
mm/inch conversion.
LCD display with backlight.
On/off/reset switch.
Automatic switch-off.
Calibration standard on side of basic instrument.
Operating temperature: -20 to 50°C.
Dimensions: 116 x 64 x 27 mm (910.334:
133 x 75 x 29 mm).
Weight basic instrument: 220 g (910.334:
260 g).
Delivery in a plastic carrying case with a
manufacturer measuring report and standard
probe.
Delivery including contact fluid.
Power supply: 2 batteries type AAA (2x AA
for 910.334).
910.334
