P. 485
Schut Geometrical Metrology HARDNESS TESTERS
Portable digital hardness testers (continued)
Optional impact devices (only for 909.470) External impact module G
External impact module D 9x higher impact energy for rough casting
Standard module. pieces etc.
External impact module DL
With thin, long probe on the impact module
for measuring in grooves, blind bores etc.
External impact module C
4x reduced impact energy for hardened
components, thin-walled materials and coatings.
Impact devices D DL C G
Max. roughness (Ra) 2 2 0.4 7
Impacting energy (Nmm) 11 11 3 90 D G
909.471 909.472
Mass of impact module (g) 5.5 7.8 3.0 20
C DL
Impact module length (mm) 147 250 141 254 909.473 909.474
Max. hardness of workpiece (HV) 940 940 1000 – � �
Max. hardness of workpiece (HB) – – – 650 � �
Min. weight of sample: �
of compact shape (kg) 5 5 1.5 15
on solid support (kg) 2 2 0.5 5
coupled on plate (kg) 0.1 0.1 0.02 0.5
Min. thickness of sample:
coupled (mm) 3 3 1 10
min. thickness of hardened layers (mm) 0.8 0.8 0.2 –
Impact body tips (for 909.470)
Item No. Description Price EUR 909.477
909.482 1 Tip for impact body D 121.00
909.483 Tip for impact body G 242.00
909.564 Tip for impact body C 121.00
909.484 Tip for impact body DL 485.00
1 Also for integrated impact body D 909.485.
Set special support rings
The set consists of
Type Description C18.320.EN.20240626
Cylindrical outside surface R10 - R15
Cylindrical outside surface R14.5 - R30
Cylindrical outside surface R25 - R50
Cylindrical inside surface R11 - R13
Cylindrical inside surface R12.5 - R17
Cylindrical inside surface R16.5 - R30
Spherical outside surface SR10 - SR15
Spherical outside surface SR14.5 - SR30
Spherical outside surface SR11 - SR13
Spherical inside surface SR12.5 - SR17
Spherical inside surface SR16.5 - SR30
Cylindrical outside surface, radius adjustable ≥ R10
© 2024, Schut Geometrische Meettechniek bv 485 Measuring instruments and systems 2023/2024
