Schut Geometrical Metrology
Granite surface plate with stand for height gauges
Correct and accurate use of height gauges de­
mand a robust and flat working table. Especially
in combination with the very advanced and ac­
curate Mitutoyo and TESA height gauges this is
a necessity in order to benefit the full potential
of these instruments.
In combination with the purchase of a TESA
or Mitutoyo height gauge, Schut Geometrical
Metrology offers granite surface plate and stand
sets in various dimensions and accuracy classes
for very compet­i­tive prices. Combinations that
make the purchase of one of these height gauges
even more attractive!
Digital protractor
Compact digital protractor to attach to a caliper
or height gauge.
 Measuring range: 180°.
 Resolution: 0.01° or 1'.
 Accuracy: ± 5'.
 Digimatic data output.
 On/off switch.
 Automatic switch-off
(adjustable).
 Preset or hold function.
 Reset.
 Reversible measuring
direction.
 Weight: 160 g.
 Delivery in a case including assembly key,
mounting bracket (clamping shaft 9 x 9 mm)
and clamping screw for height gauge.
 Power supply: 2 batteries type AAA.
Item No. Description Price EUR
855.803 Digital protractor 683.00
Options: 0.80
497.914 Spare battery type AAA 37.00
44.00
(2 needed)
905.338 Digimatic cable, 1 m
905.409 Digimatic cable, 2 m
© 2024, Schut Geometrische Meettechniek bv
HEIGHT GAUGE ACCESSORIES
The stands are very robust and the support
of the surface plate is determined on the basis
of the Bessel points. All sets are available
in surface plate sizes from 630 x 630 mm up
to 2000 x 1000 mm, all according DIN 876,
accuracy classes 1, 0 en 00.
Check our website www.Schut.com for the
most recent promotions and prices.
131.101 +
131.113 +
131.108 +
402.028
With the purchase of a height gauge:
UNIQUE SET PRICES
Surface plate 1000 x 630 x 150 mm, class 0
including stand: EUR 1,595.00
Surface plate 1000 x 630 x 150 mm, class 0
including stand, slide protection, cover,
chest of drawers and cleaner: EUR 2,450.00
Delivery ex Groningen, Netherlands
Granite plate cleaner
Special granite plate cleaner to keep the
surface of your granite surface plate clean and
useable for a long period. Dust, dirt,
grease stains, finger and hand prints
can easily be removed. A clean and
smooth surface provides low friction,
less wear and the most accurate
measurements. The non-corrosive
property of the cleaner prevents
corrosion damage to metal products.
Item No. Description Price EUR C16.311.EN.20240626
407.304 Cleaner, 500 ml 9.40
479 Measuring instruments and systems 2023/2024
