MAGNIFIERS Schut for Precision
Peak zoom magnifiers 8-16x and 10-20x
Unique stepless zoom lens with sufficient brightness in
each stage of magnification and a minimum of optical aber
ration. With click‑stop on magnifications 8/10/12/14/16x
and 10/15/20x, respectively. Equipped with scale.
Field of view: ø 20 - 10 mm or ø 13 - 7 mm.
Graduation: 0.1 mm.
For optional scales: see “Peak
scales ø 35 mm”.
904.028 905.198 905.197
Item No. Magnification Field of view Adjustment range Measuring Dimensions Price
ø/mm eye correction range/mm mm EUR
905.197 8 - 16x 20 - 10 +2.5D to –5D 16 ø 45 x 65 217.00
905.198 10 - 20x 13 - 7 +5D to –3.5D 12 ø 42 x 52 237.00
Options:
904.028 Illumination 33.40
495.153 Battery type C (2 needed) 1.50
Peak telecentric magnifier 7x Peak stand magnifier 4x
A telecentric magnifier shows objects, This practical and convenient magnifier can
which are at different distances, with the same be used for many purposes, like inspecting
magnification. In this way 3D objects, or e.g. films. The magnifier is delivered with a clear
a needle above a scale, can be shown and and a black base, which allows you, depending
measured accurately without parallax error. on the amount of light, to choose the base which
Field of view: is most suitable for your application.
Field of view: ø 45 mm.
ø 24 mm. Dimensions: 51 x 51 x 65 mm.
Measuring range Weight: 80 g.
scale: 20 mm.
Graduation: 0.1 mm.
Adjustable diaphragm
with apertures ø 0.5,
1 and 3 mm.
Dimensions:
ø 38 x 74 mm.
For optional scales:
see “Peak scales
ø 26 mm”.
Item No. Description Price EUR
905.136 Telecentric magnifier 7x 146.00 Item No. Description Price EUR C13.203.EN.20250106
including case and standard scale 905.399 Stand magnifier 4x 61.00
(for scales of ø 26 mm)
