P. 415
Schut Geometrical Metrology MAGNIFIERS
Peak scale magnifier 10x Scale magnifier with illumination 905.178
Field of view: ø 32 mm.
All-purpose scale magnifier. Aberrations are Dimensions: ø 47 x 45 x 185 mm.
avoided by the excellent achromatic lenses. Weight (without batteries): 134 g.
High resolution and large field of view. Power supply: 2 batteries type C.
Field of view: ø 35 mm.
Measuring range Set 905.195
Scale magnifier
standard scale: 30 mm.
Graduation: 0.1 mm. 10x in a set with
Dimensions: the five most fre
quently used scales
ø 46 x 44 mm. (2, 3, 7, 8 and 10).
Weight: 74 g.
Item No. Description Price EUR
905.180 Magnifier with 58.00
standard scale in a soft case
905.195 Set of magnifier 10x 109.00
and five scales
in a plastic case
905.178 Magnifier 905.180 84.00
with illumination (without batteries)
Option: 1.50
495.153 Battery type C (2 needed)
Peak scales ø 35 mm 905.181 905.182 905.183
Aside from the standard scale, various other
scales are available, each one with its own specific
application. These scales are interchangeable in
scale magnifiers like the one above.
Item No. Scale Price EUR 905.184 905.185 905.186
905.181 standard 9.50
905.182 no. 1 905.187 905.188 905.189
905.183 no. 2 11.20
905.184 no. 3 11.20 905.190 905.191 905.192 905.193 C13.208.EN.20250106
905.185 no. 4 11.20
905.186 no. 5 11.20
905.187 no. 6 11.20
905.188 no. 7 11.20
905.189 no. 8 11.20
905.190 no. 9 11.20
905.191 no. 10 11.20
905.192 no. 11 11.20
905.193 no. 12 11.20
11.20
© 2025, Schut Geometrische Meettechniek bv 415 Measuring instruments and systems 2023/2024
