MAGNIFIERS Schut for Precision

Peak scale magnifier 7x

All-purpose scale magnifier. Aberrations are
avoided by the excellent achromatic lenses.
 Field of view: ø 26 mm.
 Measuring range

standard scale: 20 mm.
 Graduation: 0.1 mm.
 Dimensions:

ø 36 x 62 mm.
 Weight: 56 g.

Item No. Description Price EUR Scale magnifier with illumination 905.138
 Field of view: ø 22 mm.
905.140 Magnifier with 42.00  Dimensions: ø 36 x 58 x 175 mm.
standard scale in a soft case  Weight (without batteries): 118 g.
905.155 Set of magnifier 7x 77.00  Power supply: 2 batteries type C.
and five scales
in a plastic case Set 905.155
905.138 Magnifier 905.140 61.00 Scale magnifier
with illumination (without batteries)
7x in a set with
the five most fre­
quently used scales
(2, 3, 7, 8 and 10).

Option: 1.50
495.153 Battery type C (2 needed)

Peak scales ø 26 mm 905.141 905.142 905.143

Aside from the standard scale, various other
scales are available, each one with its own specific
application. These scales are interchangeable in
scale magnifiers like the one above.

Item No. Scale Price EUR 905.144 905.145 905.146
905.141 no. 1 10.30
905.142 no. 2 10.30 905.147 905.148 905.149
905.143 no. 3 10.30
905.144 no. 4 10.30 905.150 905.151 905.152 905.153 C13.207.EN.20250106
905.145 no. 5 10.30
905.146 no. 6 10.30
905.147 no. 7 10.30
905.148 no. 8 10.30
905.149 no. 9 10.30
905.150 no. 10 10.30
905.151 no. 11 10.30
905.152 no. 12 10.30
905.153 standard 10.30
