P. 417
Schut Geometrical Metrology MAGNIFIERS
Peak scale magnifier 15x Peak scale magnifier 30x
Field of view: ø 20 mm. Field of view: ø 7 mm.
Measuring range standard scale: 14 mm. Measuring range standard scale: 5 mm.
Graduation: 0.1 mm. Graduation: 0.05 mm.
Dimensions: ø 35 x 33 mm. Dimensions: ø 30 x 19 mm.
Weight: 40 g. Weight: 16 g.
905.272 905.273
905.274 905.275
Item No. Description Price EUR Item No. Description Price EUR
Scale magnifier in a soft case 80.00 Scale magnifier in a soft case 77.00
905.270 905.285
Separate standard scale 16.30 Separate standard scale 18.00
Option: Scale no. 1 16.30 Option:
905.272 Scale no. 2 16.30 905.286
905.273 Scale no. 8 16.30
905.274
905.275
Peak anastigmatic scale magnifiers 4x and 7x
Magnifier with anastigmatic lens. This is a combined objective which reflects a large, undistorted
image with sharp features, very suitable for inspection of (photographic) films.
Large field of view, 905.216: ø 58 mm, Graduation scale: 0.1 mm.
905.400: ø 41 mm. Dimensions and weight:
Removable scale with mm graduation. 905.216: ø 73 x 77 mm, 272 g,
Measuring range scale 905.217: 54 mm, 905.400: ø 55 x 53 mm, 103 g.
905.401: 36 mm.
Item No. Description Price EUR C13.210.EN.20250321
905.216 Scale magnifier 4x 170.00
905.400 Scale magnifier 7x 152.00
Options:
905.217 Standard scale 36.20
23.40
for magnifier 905.216
905.400 905.216 905.401 Standard scale
for magnifier 905.400
© 2025, Schut Geometrische Meettechniek bv 417 Measuring instruments and systems 2025/2026
