MAGNIFIERS / PEN MICROSCOPES Schut for Precision

Peak head magnifiers 2.2x ... 5.2x

Because of the velcro strip, the head magnifier can be used easily. The great advantage of a head mag­
nifier is that the user has both hands free for e.g. production and assembly of precision instruments. The
head magnifier is designed in such a way that people who wear glasses can use it as well. With the extra
pair of lenses inside the head magnifier, the mag­
nification can be enhanced from 2.2x to 3.3x.

 Clear, broad and 3-dimensional view.
 Weight 905.318: 100 g,
905.317: 118 g.
905.318

Item No. Magnification Price EUR 905.317

905.318 2.2x / 3.3x 34.40
905.317 2.2x / 3.3x / 4.1x / 5.2x 43.00

Peak pen microscopes with EIM 25x ... 100x

These pen microscopes have a fixed scale and EIM system. With 905.404
standard microscopes, the magnification is upside down, but
because of the EIM system, this is not the case with
these pen microscopes.
 Dimensions: ø 20.7 x 111 mm.
 Weight: 25 - 28 g.

Item No. Magnifi- Field of Measuring Graduation Price
cation view ø/mm range/mm mm EUR

905.404 25x 3.50 3.0 0.05 163.00
905.405 50x 1.70 1.6 0.02 183.00
905.406 75x 1.10 1.0 0.01 202.00
905.407 100x 0.86 0.8 0.005 223.00

Peak pen microscopes 25x ... 100x

 Dimensions: 905.267
ø 12.4 x 127 mm.
Item No. Magnifi- Field of Measuring Graduation Price
 Weight: 13 - 16 g. cation view ø/mm range/mm mm EUR
 With a fixed scale – 41.00
– – 58.00
(only 905.263/264). – – 65.00
– – 86.00
905.267 25x 3.30 –
905.268 50x 2.00
905.269 75x 1.09
905.266 100x 0.84

With fixed scale: 3.30 3.00 0.05 71.00 C13.205.EN.20240626
905.263 25x 2.00 1.60 0.02 83.00
905.264 50x

© 2024, Schut Geometrische Meettechniek bv 412 Measuring instruments and systems 2023/2024
