P. 420
MICROSCOPES Schut for Precision
Peak stand microscopes 20x ... 200x Type 2034
These stand microscopes are available in five
versions. All five are compact and lightweight,
but are especially characterized by their large
field of view. Delivery in a case, including LED
illumination, matching standard scale and objective.
The microscopes come with a Huygens eyepiece
(magnification 10x) and with a detachable soft rubber
eye adapter. All-purpose use with high precision.
Type 2034
A scale graduation (with a 10 mm scale range)
has been engraved on the focusing ring which allows
height measurements at a resolution of 0.1 mm.
Focusing with helicoid ring.
Dimensions: ø 63 x 172 mm.
Weight (without batteries): 237 - 241 g.
Power supply: 2 batteries type AAA.
Item No. Magnification Field of view Working Measuring Graduation Price
ø/mm distance/mm range/mm mm EUR
905.320 20x 7.2 36 6 0.1 264.00
905.330 40x 3.6 18.7 3 0.05 264.00
905.340 60x 2.4 10.8 2 0.02 285.00
905.350 100x 1.45 5.7 1.2 0.01 285.00
905.355 150x 0.96 9.2 0.9 0.005 345.00
905.370 200x 0.72 6.7 0.6 0.002 409.00
Options: 0.80
497.914 Spare battery type AAA (2 needed) 14.60
905.179 LED penlight
Peak individual scales Item No. Magnification Scale Price
microscope EUR
The in the eyepiece integrated scale can be
changed, for example when the magnification of the Standard scales:
microscope changes (see “Individual objectives”). 905.321 20x no. 54 37.40
Additionally, an extra eyepiece (without scale 905.331 40x no. 64 37.40
and soft rubber eye adapter) is available, so the 905.341 60x no. 74 37.40
eyepiece doesn’t need to be disassembled each 905.351 100x no. 84 37.40
time the scale is being changed. no. 94 37.40
no. 104 37.40
905.356 150x no. 114 47.00
905.337 200x
905.388 300x
For inspection of printed matter and tools:
905.325 20x no. 55 37.40
905.335 40x no. 65 37.40
C13.213.EN.20240626
905.321 905.325 904.042 Individual eyepiece 10x 56.00
