P. 423
Schut Geometrical Metrology MICROSCOPES
Peak stand microscopes 25x ... 100x
Compact and light‑weight stand microscope
with scale. The high resolution and bright
images as well as its easy focusing make
this instrument a practical measuring aid. A
scale graduation (scale range 8 mm) has been
engraved on the focusing ring which allows
height measurements at a resolution of 0.1 mm.
With detachable soft rubber eye adapter.
Delivery in a case, with matching standard
scale.
Dimensions: ø 41.5 x 122 mm.
Weight: 83 g.
905.243/244/237/238 905.245/246/239/240
Item No. Type Magnification Price EUR
Standard scales: 25x 24.50
905.243 24 50x 24.50
905.244 13 75x 24.50
905.237 34 100x 37.40
905.238 44
Scales for inspection of printed matter
and tools:
905.245 25 25x 24.50
905.246 14 50x 24.50
905.239 35 75x 24.50 905.250
905.240 45 100x 37.40
Item No. Magnification Field of view Working Measuring Graduation Price
ø/mm distance/mm range/mm mm EUR
905.249 25x 3.3 17.0 3.0 0.05 137.00
905.250 50x 2.0 11.7 1.6 0.02 150.00
905.251 75x 1.1 11.7 1.0 0.01 159.00 C13.215.EN.20240626
905.258 100x 0.84 11.6 0.8 0.005 181.00
© 2024, Schut Geometrische Meettechniek bv 423 Measuring instruments and systems 2023/2024
