P. 428
MAGNIFIERS Schut for Precision
Light magnifiers with fluorescent or LED illumination
Large lens with a large field of view. Very suitable for production and assembly of precision
instruments.
Magnification: Lens: ø 100 mm + ø 20 mm: 909.649,
1.75x (3 dpt.): 909.648, ø 120 mm: 909650, 909651,
1.75x + 4x (3 dpt. + 12 dpt.): 909.649, ø 127 mm: 909.648.
2.25x (5 dpt.): 909.650, 909.651.
Span table clamp: 50 mm.
40 cm Dimensions and weight base 910.430:
310 x 215 mm, 4 kg.
Power supply: 230 V.
40 cm
40 cm
909.650 40 cm
30 cm 909.648
30 cm 909.648
909.649
38 cm
909.651
910.430
909.649
With circular fluorescent tube Price EUR 910.428 910.429 910.427
Item No. Description 66.00
909.650 With table clamp 84.00 Options (only for 909.648 and 909.650):
909.651 With base
Option: 8.80
909.654 Spare bulb 22 W
Item No. Description Price
EUR
With LED ring light
Item No. Description Price EUR 910.427 Table clamp 11.80
910.428 Wall mount 11.80
909.648 56 SMD-LEDs, with table clamp 93.00 910.429 Table mount 11.80 C13.327.EN.20240626
909.649 60 LEDs, with base 52.00 910.430 Base 43.00
© 2024, Schut Geometrische Meettechniek bv 428 Measuring instruments and systems 2023/2024
