Schut Geometrical Metrology                                      STEREO MICROSCOPES

Stereo zoom microscopes with auxiliary lenses SSM‑10/20

Stereo zoom microscopes with a sharp erect image and a large field of view. Equipped with a double
objective (2x/4x is used the most; also available 1x/2x and 1x/3x), so that the magnification can be
changed with a simple rotary motion. The magnification of the eyepieces is 10x (optionally 5x, 15x
and 20x). The magnification can be adjusted to your application even more with an optional auxiliary
lens (0.5x, 0.75x, 1.5x or 2x). For all accessories, please refer to the pages “SSM stereo microscope
accessories”.
                                                                 Item No. Type	 Magnification Price EUR
	 Stand with round (flattened) column and anti
drop facility.                                                   909.006 SSM‑10	 20x/40x                       212.00
                                                                 909.046 SSM‑10	 10x/20x                       212.00
	 Microscope head: 360° rotatable.                              909.036 SSM‑10	 10x/30x                       212.00
	 Viewing angle: 45°.
	 Interpupillary distance: adjustable (55 - 75 mm).
	 Left eyepiece with diopter adjustment: ± 5 dpt.               909.007 1 SSM‑20C2	 20x/40x                   264.00
	 Working distance (without aux. lens):                         909.047 1 SSM‑20C2	 10x/20x                   264.00
                                                                 909.037 1 SSM‑20C2	 10x/30x                   264.00
  72 mm.
	 Stage plate: black/                                           1	With LED illumination.
                                                                  See for accessories the pages “SSM stereo
  white (two-sided).                                             microscope accessories”.
	 Delivery incl. dust
cover and soft rub­
ber eye adapters.

                                            909.036

Illumination: LED incident light and LED
backlight

  Model SSM‑20C2 is equipped with LED
incident light and LED backlight, and the
luminous intensity is adjustable.
	 Stage plate: opal glass. Delivery incl. black/

  white stage plate.
	 Power supply: 230 Vac (50 Hz).

Type                    SSM‑10              SSM‑20C2

Eyepiece	          M 10x                    10x

Objective	         M 2x/4x,  1x/2x  or  1x/3x

Total range *	     M 5-160x,  2½-80x  or  2½-120x

Illumination            no yes

Max. object height	 mm  100                 100

Travel of rack	 mm 60                       60

Stage plate	    ø/mm    75                  95

Dimensions	 lxwxh/mm 260x170x290 270x235x330                                                     909.007
                                                                 Measuring instruments and systems 2023/2024
Weight	            kg 3.0                   4.3                                                                        C13.306.EN.20240626

*	The magnification range of the microscope in combination with
 the optional eyepieces 5‑20x and auxiliary lenses 0.5‑2x.
