P. 431
Schut Geometrical Metrology STEREO MICROSCOPE ACCESSORIES
SSM stereo microscope accessories
USB microscope cameras Item No. Description Price EUR
For viewing and saving images. They fit in
Pairs of eyepieces for SSM‑2/3/5/10/20:
the ocular (ø 30 mm) of an SSM microscope 909.050 M = 5x 50.00
and/or the adapter bushing (ø 23 mm) of the 909.051 M = 10x 50.00
models SSM‑3E/3EC2. 909.052 M = 15x 44.00
Field of view: see table. 909.053 M = 20x 44.00
Resolution: 1.3 Mpx or 5 Mpx.
Suitable for Windows and Mac OS X. Pairs of eyepieces for SSM‑E: 54.00
Measuring of distances, radii and angles. 909.055 M = 10x 74.00
Auxiliary lenses 909.057 M = 20x
The magnification can be adjusted to your Eyepieces with crosshair for SSM‑E: 59.00
application even more with an optional auxiliary 909.095 M = 10x (per piece)
lens. Note concerning stereo microscopes with 909.096 M = 20x (per piece) 50.00
a fixed stand: auxiliary lens 0.5x is not suitable,
and with auxiliary Auxiliary lenses (for SSM‑10/20/E): 61.00
lenses 1.5x and 2x 909.018 M = 0.5x 61.00
focusing on the stage 909.019 M = 0.75x 61.00
plate is not possible 909.020 M = 1.5x 61.00
(the product needs 909.021 M = 2x
to be positioned
higher). USB microscope cameras: 239.00
774.145 1.3 Mpx, ø 23 mm
909.018 - 021 774.296 1.3 Mpx, ø 23 / 30/ 30.5 mm 409.00
774.243 5 Mpx, ø 23 / 30/ 30.5 mm 579.00
Magnification Microscope magnification / Field of view/mm
objective Eyepiece 5x Eyepiece 10x Eyepiece 15x Eyepiece 20x
Stereo microscope SSM‑2:
2x 10x / ø 10.0 20x / ø 10.0 30x / ø 7.0 40x / ø 5.0
Pairs of eyepieces Stereo zoom microscope SSM‑3/5:
1x 5x / ø 20.0 10x / ø 20.0 15x / ø 15.0 20x / ø 10.0
2x 10x / ø 10.0 20x / ø 10.0 30x / ø 7.0 40x / ø 5.0
3x 15x / ø 7.0 30x / ø 7.0 45x / ø 5.0 60x / ø 3.5
4x 20x / ø 5.0 40x / ø 5.0 60x / ø 3.5 80x / ø 2.5
Stereo zoom microscope SSM‑10/20 (without auxiliary lens):
909.055 1x 5x / ø 20.0 10x / ø 20.0 15x / ø 15.0 20x / ø 10.0
909.051
2x 10x / ø 10.0 20x / ø 10.0 30x / ø 7.0 40x / ø 5.0
Soft rubber eye adapters
3x 15x / ø 7.0 30x / ø 7.0 45x / ø 5.0 60x / ø 3.5
4x 20x / ø 5.0 40x / ø 5.0 60x / ø 3.5 80x / ø 2.5
Item No. Description Price EUR Magnification Magnification / Field of view/mm Field of view camera/mm
909.089 Per pair 4.70 objective Eyepiece 10x Eyepiece 20x 774.145 774.296 774.243
Stereo microscope with stepless zoom SSM‑E (without auxiliary lens):
909.089 from 1x 10x / ø 20.0 20x / ø 10.0 4.5 x 3.3 1 6.8 x 5.0 1 19.0 x 14.0 1
to 4x 40x / ø 5.0 80x / ø 2.5 1.2 x 0.8 1 1.4 x 1.0 1 2.7 x 2.0 1
from 1x
to 4x 5.6 x 4.1 2 18.0 x 12.0 2
1.34 x 1.0 2 2.4 x 1.8 2
C13.308.EN.20240626
1 Camera intake in adapter bushing.
2 Camera intake in ocular.
