Schut Geometrical Metrology VIDEO MICROSCOPES

Dino-Lite USB video measuring microscopes (continued)

Item No. 774.081 774.088 774.210 774.106 774.024 1 774.250 1 774.277 1 774.278 1 774.280 1

Type AM4113T AM4113ZT AM4115TL AM4013MZTL AM4115ZTL AM4115TF AF4115ZT AF4915ZT AF4915ZTL
Price EUR 349.00
Magnification (stepless) 10-70x 429.00 539.00 619.00 629.00 639.00 639.00 929.00 929.00
10-70x 10-140x 10-90x 10-140x 10-70x 20-220x 20-220x 10-140x

Magnification (fixed) 200x 200x – – – – – – –

Resolution px 1.3 M 1.3 M 1.3 M 1.3 M 1.3 M 1.3 M 1.3 M 1.3 M 1.3 M

FLC 2 – – – – – – ✓ ✓ ✓

EDOF/EDR 3 – – – – – – – ✓ ✓

AMR 4 – – – – – – – ✓ ✓

Field of view (mm)

min. magnif. 19.8x14.9 19.8x14.9 39.0x31.2 19.8x14.9 39.0x31.2 39.0x31.2 19.5x15.6 19.5x15.6 39.0x31.2

max. magnif. 1.7x1.2 1.7x1.2 2.8x2.2 4.4x3.3 2.8x2.2 5.6x4.5 1.8x1.4 1.8x1.4 2.8x2.2

Polarizer – ✓ – ✓ ✓ – ✓ ✓ ✓

Long working distance – – ✓ ✓ ✓ ✓xtra – – ✓
mm -2..48 -2..48 30..234 46..151 30..234 115..480 4..60 4..60 30..234

Removable front – – ✓ – ✓ ✓ ✓ ✓ ✓

Aluminum housing – – – ✓ – – – – –

Removable cable for – – – – – – ✓ ✓ ✓
WiFi module

USB interface 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0

Item No. 774.330 774.314 6 774.216 1 774.251 1 774.246 1 774.228 1 774.229 1 774.252 1 774.253 1

Type AM7515MZT2P AM4917MZT AM7115MZTL AM73115MTF AM73115MZT AM7915MZT AM7915MZTL AM73915MZT AM73915MZTL

Price EUR 1,099.00 1,169.00 929.00 1,099.00 1,099.00 1,169.00 1,169.00 1,399.00 1,399.00

Magnification (stepless) 1 30-220x 20-220x 10-140x 10-70x 10-220x 10-220x 10-140x 10-220x 10-140x

Laser pointer ✓ – – – – – – – –

Resolution px 5 M 1.3 M 5 M 5 M 5 M 5 M 5 M 5 M 5 M

FLC 2 ✓ ✓ eFLC ✓ ✓ ✓ ✓ ✓ ✓ ✓

EDOF/EDR 3 – ✓ – – – ✓ ✓ ✓ ✓

AMR 4 ✓ ✓ – – – ✓ ✓ ✓ ✓

Field of view (mm)

min. magnif. 3.0x2.2 19.5x14.7 39.0x31.2 39.0x31.2 37.8x28.3 37.8x28.3 39.0x31.2 37.8x28.3 39.0x31.2

max. magnif. 1.8x1.3 1.8x1.3 2.8x2.2 5.6x4.5 1.8x1.3 1.8x1.3 2.8x2.2 1.8x1.3 2.8x2.2

Polarizer ✓ ✓ ✓ – ✓ ✓ ✓ ✓ ✓

Long working distance – – ✓ ✓xtra – – ✓ – ✓
mm 4.5..11.9 4..60 30..234 115..480 12..136 12..136 30..234 12..136 30..234

Removable front ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓

Aluminum housing ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓

USB interface 2.0 2.0 5 2.0 3.0 3.0 2.0 2.0 3.0 3.0

1 New Edge generation with better optics and exchangeable front sides. C13.320.EN.20240626
2 FLC: Flexible Light Control. eFLC: 2 different intensities possible.
3 EDOF: Extended Depth of Field / EDR: Extended Dynamic Range.
4 AMR: Auto-Magnification Read.
5 Detachable micro USB cable (included).
6 New Edge plus generation with indicative depth measurement.
