VIDEO MICROSCOPES Schut for Precision

Dino-Lite USB video measuring microscopes

Very versatile and compact digital microscopes with measuring functions for various medical, in­
dustrial and educational applications. Optical product inspection can even be performed around your
production machine; thanks to the stepless magnification and LED illumination you can display your
products very clearly on the screen. Images can be saved as a picture or video file. Geometrical forms,
such as distances, radius and angles can be measured.

 Magnification: stepless or fixed. Also available:
 Resolution: 1.3 Mpx (1280 x 1024 px) or – models with magnification up to 900x or

5 Mpx (2592 x 1944 px). coaxial light,
 Illumination: 8 LED white ring light. – models with laser pointer,
 With software for Windows and Mac OS X – with PAL, VGA or DVI connection for live

(limited support under Mac OS X). images on TV screen, monitor or beamer,
 Measuring and calibration function and edge – with special illumination by near‑UV,

detection. near‑IR, fluorescent or stroboscopic LEDs,
 Plastic or aluminum housing. – WiFi streamer or WiFi module for a wireless
 Dimensions: ø 32 x 120 mm.
 Connection and power supply: connection with a tablet or a smartphone,
– ESD-safe models available,
USB cable (1.8 m). – USB 3.0 models with a higher frame rate,
– models with extra long working distance for a

large field of view.

774.228

Download the
brochure from

Schut.com

774.278
774.278
+ 774.281

C13.313.EN.20240626

© 2024, Schut Geometrische Meettechniek bv 434 Measuring instruments and systems 2023/2024
