P. 433
Schut Geometrical Metrology STEREO MICROSCOPE ACCESSORIES
SSM stereo microscope accessories (continued)
Large stand Stand with illumination
Base: 255 x 255 mm. Equipped with LED incident light and back
Column height: 390 mm.
Arm length: 490 mm. light. The luminous intensity is adjustable.
Height adjustment: Column height: 185 mm.
60 mm.
908.997 Microscope heads 909.405
With or without 909.092
LCD microscope head
Screen: 8" color. camera connection.
CCD: 1/3" color.
Zoom lens: 0.65 - 5.5. 909.406
Magnification: 10 - 85x.
Working distance: 909.093
10.5 cm.
Crosshair can be toggled on/off.
Field of view:
from 1.3 x 1.8 mm (M = 85x)
to 12 x 16 mm (M = 10x).
Item No. Description Price EUR
Microscope stands: 247.00
908.997 Large stand 144.00
909.405 Stand with illumination 33.60
870.006 1 Column 400 mm
909.405 Microscope heads: 377.00
+ 909.406 909.092 Microscope head 436.00
+ 870.006 909.093 Microscope head with 1,137.00
+ 334.695 29.00
© 2024, Schut Geometrische Meettechniek bv camera connection
909.406 2 LCD microscope head
334.695 Mini AC adapter
12 Vdc, 1 A
1 To be used with stand 909.405 for a larger Z axis C13.312.EN.20240626
range.
2 Adapter 334.695 required.
433 Measuring instruments and systems 2023/2024
