Schut Geometrical Metrology GLASS RULERS
Glass rulers L = 50 ... 300 mm
Very accurate glass rulers, made from clear glass with a 0.1 or 0.5 mm graduation. Ideal for
checking the magnification accuracy of profile projectors and microscopes, as well as the table feed
accuracy of measuring equipment.
Graduation: 0.1 or 0.5 mm.
Accuracy: (1.5 + 2L/1000) µm;
L = measuring length in mm. 910.255
Material: sodium glass. 910.521
Expansion coefficient: 8.6·10‑6/°C.
Thickness: 5 mm.
Width: 30 mm.
With serial number.
Delivery in an alu1m0 inum carrying case with a1 10
manufacturer m1 easuring report.
4.8 100.5
4.9 100.1
1
1 0.3 4.8 0.5 2.5
4.9 0.1 0.4 3.5
0.6 4.25
5
0.3 2.5
0.4 3.5
0.6 4.25
5
Graduation: 0.1 mm Graduation: 0.5 mm
Item No. Measuring Graduation Line thickness Total length Weight Price
Gramdumation: 0.5 mm graduation/mm mm g EUR
Graduation: 0.1 mmrange/mm
80 29 206.00
910.321 0 - 50 0.1 0.01 80 29 206.00
910.322 0 - 50 0.5 0.1 130 47 275.00
910.255 0 - 100 0.1 0.01 130 47 275.00
910.521 0 - 100 0.5 0.1 230 83 393.00
910.256 0 - 200 0.1 0.01 230 83 393.00
910.522 0 - 200 0.5 0.1 330 119 593.00
910.257 0 - 300 0.1 0.01 330 119 593.00
910.523 0 - 300 0.5 0.1
Electronic carbon scales for magnifier
Measuring range: 0 - 1450 mm. Delivery in a wooden case with a
Resolution: 0.01 mm. manufacturer measuring report.
Intake magnifier: ø 41 mm.
mm/inch conversion. Power supply: 1 battery type CR2032.
Proximity data output.
Reset/preset. 838.715
Excl. magnifier (905.180).
Item No. Measuring Accuracy Length Weight Price EUR
range/mm mm mm/A kg
838.715 0 - 450 ± 0.03 720 1 1,641.00
838.716 0 - 750 ± 0.03 1020 1.9 2,170.00
838.717 0 - 1150 ± 0.05 1420 3 2,970.00
838.718 0 - 1450 ± 0.06 1720 3.7 4,340.00
Options: Spare battery type CR2032 0.50 996.664 C13.331.EN.20240626
495.157 Magnifier with standard scale 905.181 58.00
905.180 Holder for Dino-Lite USB measuring microscopes 1 56.00
996.664
1 For Dino-Lite Edge models with normal working distance; magnification approx. 30x.
