Schut Geometrical Metrology WELDING SEAM GAUGES AND CALIPERS

Set of welding seam gauges Welding seam gauge

 For weld thickness: 3 - 12 mm. For measurement of
 Up to 7 mm increasing welding seams.
 Graduation: 0.2 mm.
with 0.5 mm, plus 8,  Stainless steel.
10 and 12 mm.  Delivery in a soft case.
Total: 12 pieces.
 Bright steel.

Item No. Description Price EUR Item No. Description Price EUR
856.438 Welding seam gauge 46.00
856.452 Welding seam gauges 12.80

Welding seam calipers 836.423
906.429
For measurement of welding seams.
 Measuring range: 0 - 20 mm.
 Analog: vernier 0.1 mm,

digital: resolution 0.01 mm.
 Delivery in a soft case (836.423) or a plastic

case (906.429).
Analog
 Stainless construction.
Digital
 mm/inch conversion.
 On/off switch.
 Reset.
 Power supply: 1 battery type V357.

90°

90° 60° 70°

The angles (60°, 70°, 80° and 90°) 70° Item No. Measuring Price
80° serve as an aid for checking the range/mm EUR
angle of the hole to be welded.

70°mm/inchmm/inch Analog: 0 - 20 19.90
60° 836.423

mm00.00 ZERO ZERO Digital:
906.429
90° ON mm 00.00

OFF ON 0 - 20 59.00

OFF C17.203.EN.20250702

90° 60° 80° Option:
836.535 Battery type V357 0.90
80°

© 2025, Schut Geometrische Meettechniek bv 405 Measuring instruments and systems 2025/2026
