THREAD CUTTING TOOL GAUGES Schut for Precision

Center gauges

For checking thread cutting tools for Whitworth thread 55° or metric thread 60°.

856.444

Item No. Description Price EUR 856.445
856.444 Whitworth 55° 2.40
856.445 Metric 60° 2.40

Thread cutting tool gauges

Item No. Description Price EUR

856.446 Universal thread cutting tool 9.20
gauge for angular thread and flat thread

856.447 Trapezoidal thread cutting 10.20
tool gauge for trapezoidal thread DIN 103
(30°, 2 - 12 mm)

856.446 856.449 Combined lathe and 10.20
thread cutting tool gauge for
– cutting tool wedge angle,
– trapezoidal thread DIN 103
(30°, 2 - 12 mm), and
– angular thread (40° - 80°)

856.451 Thread cutting tool gauge for 10.20
– rectangular thread,
856.447 – trapezoidal thread DIN 103
(30°, 2 - 12 mm), and
– angular thread (55° and 60°)
