GAUGES                                                                                   Schut for Precision

LMW thread plug and ring gauges (continued)

  Hardened steel thread plug gauges and thread ring gauges. Manufactured according ANSI B1.2
class 2B (thread plug) and BS 919 2A (thread ring). Manufactured according ANSI B1.2 class 2A
available on request.
For American screw thread UNF

Indication 	     Thread plug	    Price	  Thread ring	    Price	  Thread ring	    Price
UNF              Go/NoGo	        EUR     Go	             EUR     NoGo	           EUR

	 No   0	-	80    823.000	      213.00    823.001	      153.00    823.002	      153.00
	 No   1	-	72    823.003	      180.00    823.004	      128.00    823.005	      128.00
	 No   2	-	64    823.006	      169.00    823.007	      120.00    823.008	      120.00
	 No   3	-	56    823.009	      158.00    823.010	      114.00    823.011	      114.00
	 No   4	-	48    823.012	      155.00    823.013	      106.00    823.014	      106.00
	 No   5	-	44    823.015	       72.00    823.016	       66.00    823.017	       66.00
	 No   6	-	40    823.018	       70.00    823.019	       63.00    823.020	       63.00
	 No   8	-	36    823.021	       66.00    823.022	       58.00    823.023	       58.00
	 No 10	-	32     823.024	       64.00    823.025	       57.00    823.026	       57.00
	 No 12	-	28     823.027	       63.00    823.028	       56.00    823.029	       56.00
	   1/4	 -	28    823.030	       62.00    823.031	       56.00    823.032	       56.00
	   5/16	 -	24   823.033	       64.00    823.034	       59.00    823.035	       59.00
	   3/8	 -	24    823.036	       65.00    823.037	       63.00    823.038	       63.00
	   7/16	 -	20   823.039	       69.00    823.040	       68.00    823.041	       68.00
	   1/2	 -	20    823.042	       74.00    823.043	       77.00    823.044	       77.00
	   9/16	 -	18   823.045	       77.00    823.046	       86.00    823.047	       86.00
	   5/8	 -	18    823.048	       79.00    823.049	       94.00    823.050	       94.00
	   3/4	 -	16    823.051	       88.00    823.052	      109.00    823.053	      109.00
	   7/8	 -	14    823.054	       98.00    823.055	      125.00    823.056	      125.00
	 1	 -	12        823.057	      108.00    823.058	      144.00    823.059	      144.00
	 11/8	 -	12     823.060	      127.00    823.061	      166.00    823.062	      166.00
	 11/4	 -	12     823.063	      133.00    823.064	      182.00    823.065	      182.00

Indication 	     Thread plug	  Price	    Thread plug	  Price	    Thread ring	    Price	  Thread ring	    Price
UNF              Go	           EUR       NoGo	         EUR       Go	             EUR     NoGo	           EUR
	 13/8    	-	12
	 11/2	 -	12     823.066	      83.00     823.067	      74.00     823.068	      201.00    823.069	      201.00
                 823.070	      89.00     823.071	      81.00     823.072	      216.00    823.073	      216.00

  Hardened steel tapered thread plug and thread ring gauges NPT for sealing pipe thread.
Manufactured according ANSI/ASME B1.20.1.
For sealing pipe thread

Indication 	     Thread plug	    Price	  Thread ring	    Price
NPT..."          Go/NoGo	        EUR     Go/NoGo	        EUR

	   1/16         822.600	      181.00    822.601	      258.00
	   1/8          832.841	      187.00    832.842	      264.00
	   1/4          832.843	      198.00    832.844	      278.00
	   3/8          832.845	      214.00    832.846	      293.00
	   1/2          832.847	      233.00    832.848	      318.00
	   3/4          832.849	      259.00    832.850	      350.00
	1               832.851	      300.00    832.852	      396.00
	 11/4           822.620	      359.00    822.621	      463.00
	 11/2           822.622	      404.00    822.623	      511.00
	2               822.624	      498.00    822.625	      623.00
	 21/2           822.626	      567.00    822.627	      714.00
	3               822.628	      691.00    822.629	      914.00

                                                                                                                 C12.326.EN.20250605

© 2025, Schut Geometrische Meettechniek bv             398       Measuring instruments and systems 2025/2026
