TABLES / GAUGES Schut for Precision
Thread and tolerance tables 835.162
835.163
Thread table 835.164
Table with all standard international thread
indications: metric, BSW, Gas, BSF, Pg, BA,
UNC, UNF, UNEF, EG-M and EG-MF.
Tolerance table
Table compromising all tolerances and fits
according ISO 286‑2, up to 500 mm (table with
over 6400 pairs of tolerance values for internal
and external measurements).
Conversion table mm/inch
For converting from mm to inch and from
inch to mm.
Item No. Description Price EUR
835.162 Thread table 58.00
835.163 Tolerance table 58.00
835.164 Conversion table mm/inch 58.00
Flat thickness gauge
Gauge to measure, among others, the thickness of steel plating.
Measuring range: 1 - 13 mm.
Graduation: 0.5 mm.
Stainless steel.
Item No. Measuring range/mm Price EUR
907.899 1 - 13 6.90
Screw pitch gauges
Item No. Type of thread Number of blades Price EUR
856.456 Metric 24 3.50
856.457 Whitworth 28 5.00
856.458 BSP 6 3.10
856.459 Metric/Whitworth 52 7.80
856.460 Metric/Whitworth/BSP 58 10.90
856.461 UNC/UNF 30 4.30
Thread Angle Number of Blades C12.214.EN.20250106
blades
Metric 60°
Whitworth 55° 24 Pitch/mm: 0.25/0.3/0.35/0.4/0.45/0.5/0.6/0.7/0.75/0.8/0.9/1.0/1.25/1.5/1.75/2.0/
BSP 55° 2.5/3.0/3.5/4.0/4.5/5.0/5.5/6.0
UNC/UNF 60°
28 Threads per inch: 62/60/48/40/36/32/30/28/26/25/24/22/20/19/18/16/14/13/12/11/
10/9/8/7/6/5/4.5/4
6 Threads per inch: 28/19/14/11/10/8
30 Threads per inch: 42/40/38/36/34/32/30/28/27/26/24/22/20/18/16/15/14/13/12/11.5/
11/10/9/8/7/6/5.5/5/4.5/4
