ANGLE AND RADIUS GAUGES Schut for Precision

Angle gauge set Angle gauges

 Measuring range: 5 - 90°  Measuring range: 1 - 45°.
(supplementary angles: 90 - 175°).  Number of blades: 20.
 Angles: 1° - 2° - 3° - 4° - 5° - 6° - 7° - 8° - 9° -
 Increment: 5° (18 pieces).
 Multiple angles per angle gauge: 10° - 12° - 14° - 16° - 18° - 20° - 25° -
30° - 35° - 40° - 45°.
– primary angles (1, 2 *, 3, 4),
– supplementary angles (5, 6), and
– ½ primary angles (7, 8).
 Delivery in a soft case.

3 2*
5
8
6 1
4
7

* Angle 2: only with the angle
gauges from 20°.

Item No. Description Price EUR Item No. Description Price EUR
909.410 Angle gauge set 31.30 908.798 Angle gauges 27.20

Radius gauges Shape and radius gauge

 Measuring range radius: 1 - 25 mm. This stainless steel gauge can be used to
 Increment: adopt various complex shapes of tools and
work­pieces. When the gauge is pressed against
1 - 3 mm: 0.25 mm, the part which has to be checked, it takes on the
3.5 - 20 mm: 0.5 mm, shape of this part. Because of the graduation
> 20 mm: 1.0 mm. (mm) on the case, the shape can be checked
 Includes blades for both inside and outside easily.
radii.
Because the tracers were supported under
pressure, they don’t move on their own.

907.767

Item No. Radius range/ Number Price
mm of blades EUR
17 + 17 10.60
907.766 1 - 7 16 + 16 9.90 Item No. Measuring range/mm Price EUR C17.204.EN.20250702
907.767 7.5 - 15 15 + 15 9.90
907.768 15.5 - 25 836.319 150 x 40 19.60
