Schut Geometrical Metrology STRAIGHT EDGES

Steel straight edges for mounting

I‑shaped construction with wide and extra wide measuring faces for application of spirit levels.
 Length: 500 - 3000 mm.
 Flatness of the measuring faces

according DIN 874.

DIN 874/1 DIN 874/0

Item No. Dimensions/mm Price EUR Item No. Dimensions/mm Price EUR

406.630 1 3000 x 140 x 40 1,178.00 406.613 1000 x 100 x 30 431.00

With extra wide measuring faces: 301.00 With extra wide measuring faces:
406.636 500 x 80 x 40 406.616 1 1500 x 160 x 50 770.00
406.637 750 x 80 x 40 332.00
406.644 1 2500 x 160 x 50 1,129.00
406.631 1 3000 x 180 x 60 1,774.00

Aluminum straight edge 1,306.00
406.651 2 1000 x 100 x 40

1 Delivery ex Groningen, Netherlands.
2 Highly corrosion resistant and high insulation.

Cast iron straight edges with handles

Especially suitable for measuring small surfaces.
 Tension free.
 Flatness and parallelism according DIN 876.
 DIN 876/1: hand scraped,

DIN 876/0: fine scraped.
 Both measuring faces are flat and parallel

matched in pairs.

Dimensions Weight DIN 876/1 DIN 876/0
l x w/mm approx./kg Item No. Price EUR Item No. Price EUR

500 x 35 12 396.00 403.700 330.00
750 x 50 17 403.706 633.00 403.701 502.00
1000 x 56 25 403.707 1 1,255.00 403.702 1 751.00
1500 x 70 65 403.708 1
2000 x 80 90 403.704 1 2,480.00 C09.313.EN.20240626

1 Delivery ex Groningen, Netherlands.
