Schut Geometrical Metrology                                                      PROTRACTORS

Universal digital bevel protractor

  This stainless steel, digital bevel protractor is available with blades from 150 to 1000 mm. The
blades and all the measuring faces are hardened.

	 Measuring range: ± 360°.                                 	 Control with 5 keys for several functions.
	 Resolution: 1', or decimal 0.01°.                        	 Fine adjustment.
	 Accuracy: ± 2'.                                          	 Delivery in a wooden case with 150 mm
	 Repeatability: 1'.
	 Indication switchable from degrees and                     blade.
                                                            	 Power supply: 1 battery type CR2032.
  minutes to decimal degrees.                               	 Also available in heavy duty type (855.805).
	 + and - direction reversible.
	 Per 90° adjustable.
	 Data output, Mitutoyo Digimatic compatible.
	 On/off switch.
	 Reset/preset/hold functions.

                                                                           855.812 855.813  855.815

                                                                                            855.805

Item No. Description                        Price EUR       Single blades

855.820 Bevel protractor                    809.00          Item No. Blade length/mm        Price EUR
                                                                                                   7.50
Options:                                     0.50           909.380 	       150                    9.90      C08.203.EN.20250702
495.157 Battery type CR2032                 44.00           909.381 	       200
855.812 Acute angle attachment                              909.382 	       300                   12.60
855.813 Stand                                               909.383 	       500                   19.50
855.815 Height Gauge Holder                                 855.827 	      1000                 355.00
905.409 Data cable 2 m
