Page 336 - Schut Catalog
P. 336
PROTRACTORS Schut for Precision
Universal digital bevel protractors
Digital bevel protractors made of stainless steel, with blades of 150, 200 or 300 mm. The blades
and all the measuring faces are hardened.
Measuring range (switchable): 1x 360°, Automatic switch-off after 10 minutes of idle
2x 180°, time with storage of the displayed measuring
4x 90°. value.
Resolution: 1', or decimal 0.01°. Proximity data output.
Accuracy: ± 2'. Reset/preset/hold functions.
Clamping spring system for blade. Fine adjustment.
Indication switchable from degrees and Power supply: 1 battery type CR2032.
minutes to decimal degrees.
856.688
Complete bevel protractors Single blades
Item No. Blade length/mm Price EUR Item No. Blade length/mm Price EUR
45.00
856.688 150 1,018.00 856.685 150 56.00
856.689 200 1,029.00 856.693 200 60.00
856.690 300 1,039.00 856.687 300
Options: 0.50
495.157 Battery type CR2032
856.694 Prism base 74.00
856.695 Ledge 57.00 C08.202.EN.20250106
840.666 Proximity USB cable (2 m) 250.00
856.694 856.695
© 2025, Schut Geometrische Meettechniek bv 336 Measuring instruments and systems 2023/2024
