Page 332 - Schut Catalog
P. 332
STRAIGHT EDGES Schut for Precision
Bridge-type straight edges Item No. l x w Weight Flatness Price
mm kg µm EUR
Made of special close-grained cast iron.
Tension free. DIN 876/1:
Flatness according DIN 876: 403.658 500 x 40 6 15 212.00
403.659 750 x 45 9 18 235.00
class 1: hand scraped, 403.680 1000 x 50 17 20 424.00
class 0: fine scraped. 403.690 1 1500 x 60 45 25 904.00
403.692 1 2000 x 70 65 30 1,376.00
Triangular straight edges 403.698 1 3000 x 90 210 40 2,660.00
DIN 876/0:
On two sides scraped, triangular straight edge 403.657 500 x 40 6 6 255.00
with screwed-in handles. The edge between the 403.660 750 x 45 9 7 276.00
scraped sides (45° or 60°) has been accurately 403.679 1000 x 50 17 8 521.00
processed. The third side has been ground, and 403.691 1 1500 x 60 45 10 1,155.00
recessed for weight reduction at the larger types 403.696 1 2000 x 70 65 12 1,712.00
(from 500 mm). 403.697 1 3000 x 90 210 16 3,050.00
Tension free. 1 Delivery ex Groningen, Netherlands.
Flatness of both scraped sides according
Item No. l x w/mm Weight/kg Price EUR
DIN 876:
class 1: hand scraped, Triangular straight edge 45°, DIN 876/1:
class 0: fine scraped. 403.525 250 x 50 2 158.00
403.550 500 x 75 7 341.00
403.575 750 x 90 15 537.00
403.600 1 1000 x 120 27 806.00
Triangular straight edge 45°, DIN 876/0:
403.524 250 x 50 2 213.00
403.549 500 x 75 7 425.00
403.574 750 x 90 15 640.00
403.599 1 1000 x 120 27 967.00
Triangular straight edge 60°, DIN 876/1:
403.425 250 x 45 3 171.00
403.450 500 x 60 6 322.00
403.475 750 x 90 16 512.00
403.500 1 1000 x 100 28 757.00
Triangular straight edge 60°, DIN 876/0:
403.424 250 x 45 3 210.00
403.449 500 x 60 6 406.00
403.474 750 x 80 16 617.00
403.499 1 1000 x 100 28 941.00 C09.207.EN.20240626
1 Delivery ex Groningen, Netherlands.
© 2024, Schut Geometrische Meettechniek bv 332 Measuring instruments and systems 2023/2024
