P. 326
STRAIGHT EDGES Schut for Precision
Bright steel and stainless steel straight edges DIN 874
High quality wooden cases for straight edges are optionally available. Please see the wooden cases
for straight edges section for these wooden cases.
Length: 500 - 3000 mm. Flatness of the measuring faces according
Class 0 and 1: rectangular cross-section up DIN 874.
to length 1500 mm, from length 2000 mm Delivery with a manufacturer measuring
I‑shaped with two grip slots. report (the rectangular version has the
Class 2: rectangular cross-section. manufacturer measuring report engraved on
the straight edge).
776.601 776.587 776.583
Class Dimensions/mm Weight/kg Item No. Price EUR Item No. Price EUR
B right steel Stainless steel
DIN 874/0 500 x 50 x 10 2.0 7 76.569 80.00 776.590 140.00
750 x 50 x 10 3.0 776.570 112.00 776.591 211.00
1000 x 60 x 12 5.7 7 76.571 198.00 7 76.592 340.00
1500 x 70 x 15 12.4 7 76.572 2 369.00 776.593 2 624.00
2000 x 80 x 15 13.0 7 76.573 1,2 680.00 776.594 1,2 1,238.00
2500 x 100 x 16 22.0 776.574 1,2 1,002.00 776.595 1,2 1,956.00
3000 x 120 x 18 36.0 7 76.575 1,2 1,512.00 776.596 1,2 3,430.00
DIN 874/1 500 x 40 x 8 1.3 7 76.576 44.00 7 76.597 81.00
750 x 50 x 10 3.0 776.577 79.00 776.598 145.00
1000 x 50 x 10 4.0 776.578 95.00 7 76.599 217.00
1500 x 60 x 12 8.4 7 76.579 2 175.00 7 76.600 2 425.00
2000 x 70 x 15 12.0 7 76.580 1,2 463.00 776.601 1,2 936.00
2500 x 80 x 15 17.0 776.581 1,2 652.00 7 76.602 1,2 1,200.00
3000 x 100 x 16 26.0 776.582 1,2 992.00 776.603 1,2 2,140.00
DIN 874/2 500 x 30 x 6 0.7 7 76.583 28.40 7 76.604 56.00 C09.308.EN.20240626
750 x 40 x 8 2.0 776.584 52.00 776.605 110.00
1000 x 40 x 8 2.5 776.585 62.00 7 76.606 144.00
1500 x 50 x 10 5.8 7 76.586 2 118.00 776.607 2 274.00
2000 x 60 x 12 11.2 7 76.587 2 180.00 7 76.608 2 510.00
2500 x 70 x 15 20.6 776.588 2 350.00 7 76.609 2 936.00
3000 x 80 x 15 28.2 7 76.589 2 539.00 7 76.610 2 1,332.00
1 I-shaped with two grip slots.
2 Delivery ex Groningen, Netherlands.
© 2024, Schut Geometrische Meettechniek bv 326 Measuring instruments and systems 2023/2024
