Schut Geometrical Metrology                                                    PARALLELS

Steel parallel blocks

  Parallels to position and layout workpieces in e.g. clamping jaws for drilling, grinding, milling and
measuring. The workpieces and assemblies can easily be set up to the desired working height.

	 Parallelism of the two measuring faces: 	            	 Ground in matched pairs.
  ± 0.005 mm.                                           	 Produced of a high-grade steel alloy.
                                                        	 Delivery in a wooden case with a declaration
	 Size deviation (height): ± 0.01 mm.
	 Hardness: 55 HRC.                                      of conformity.

                                      Item No. Length 	 Price     Width 	             Height
                                                     mm EUR        mm                  mm

                                      Set of 12 pairs:   82.00  		 10
                                     909.800 	 100       99.00  	          	 14 - 16 - 18 - 20 - 22 - 24 -
                                     909.804 	 125      117.00  	          	 26 - 28 - 30 - 32 - 35 - 40
                                     906.995 	 150              		 10
                                                                	          		 14 - 16 - 18 - 20 - 22 - 24 -
906.996                               Set of 14 pairs:   92.00  	8         	 26 - 28 - 30 - 32 - 35 - 40 -
                                     909.802 	 100      117.00  	 10       	 45 - 50
                                     909.805 	 125      132.00  	 12
                                     906.996 	 150              	 14       	 11 - 16 - 21 - 26 - 31 - 36
                                                                           	 13 - 18 - 23 - 28 - 33 - 38
          (Only available in sets.)   Set of 24 pairs:  219.00             	 15 - 20 - 25 - 30 - 35 - 40
                                     909.803 	 100      241.00             	 17 - 22 - 27 - 32 - 37 - 42
                                     909.806 	 125      289.00
                                     906.997 	 150

  Adjustable parallel set

  Set of 6 adjustable parallels. The parallels consist of 2 precisely ground tapered parts dovetailed
together to ensure easy setting. These allow you to quickly clamp a workpiece in the correct position
on a workbench, set a measuring instrument or check the internal dimensions of two parallel surfaces.

Parallel  Measuring 	 Measuring face
A         range/mm length/mm
B
C         	   9.5	-	12.7                      45        Item No. Size/mm       Price EUR                     C09.311.EN.20250321
D         	 12.7	-	17.5                       54        910.400 9.5 - 57.1 mm        61.00
E         	 17.5	-	23.8                       69
F         	 23.8	-	33.3                       90
          	 33.3	-	44.5                     107
          	 44.5	-	57.1                     117
